Generic Client Model send parameters. This structure is used to pass parameters to the Generic Client Model for sending messages. It includes the element ID, model pointer, state parameters, opcode, destination address, network index, and application index. More...
#include <meshx_gen_client.h>
Data Fields | |
| meshx_ptr_t | model |
| uint16_t | opcode |
| uint16_t | addr |
| uint16_t | net_idx |
| uint16_t | app_idx |
| meshx_gen_cli_set_t * | state |
Detailed Description
Generic Client Model send parameters. This structure is used to pass parameters to the Generic Client Model for sending messages. It includes the element ID, model pointer, state parameters, opcode, destination address, network index, and application index.
Definition at line 31 of file meshx_gen_client.h.
Field Documentation
◆ addr
| uint16_t meshx_gen_client_send_params::addr |
Destination address associated with the message.
Definition at line 35 of file meshx_gen_client.h.
◆ app_idx
| uint16_t meshx_gen_client_send_params::app_idx |
Application key index associated with the message.
Definition at line 37 of file meshx_gen_client.h.
◆ model
| meshx_ptr_t meshx_gen_client_send_params::model |
Model context associated with the message.
Definition at line 33 of file meshx_gen_client.h.
◆ net_idx
| uint16_t meshx_gen_client_send_params::net_idx |
Network index associated with the message.
Definition at line 36 of file meshx_gen_client.h.
◆ opcode
| uint16_t meshx_gen_client_send_params::opcode |
Opcode associated with the message.
Definition at line 34 of file meshx_gen_client.h.
◆ state
| meshx_gen_cli_set_t* meshx_gen_client_send_params::state |
State parameters associated with the message.
Definition at line 38 of file meshx_gen_client.h.
The documentation for this struct was generated from the following file:
