meshx_ble_mesh_cmn_def.h File Reference

Common definitions for BLE Mesh models and opcodes in the MeshX framework. More...

Go to the source code of this file.

Macros
#define	MESHX_BIT(nr)
#define	MESHX_ARRAY_SIZE(_arr)
#define	MESHX_ADDR_IS_UNICAST(_addr)
#define	MESHX_ADDR_BROADCAST(_addr)
#define	MESHX_ADDR_IS_GROUP(_addr)
#define	MESHX_ADDR_GROUP_START   0xC000
#define	MESHX_ADDR_UNASSIGNED   0x0000
#define	MESHX_KEY_UNUSED   0XFFFF
#define	MESHX_MODEL_OP_1(b0)
#define	MESHX_MODEL_OP_2(b0, b1)
#define	MESHX_MODEL_OP_3(b0, cid)
#define	MESHX_MODEL_ID_SIG_START   0x1000
	BLE Mesh models related Model ID and Opcode definitions.
#define	MESHX_CID_SIG   0xFFFF
#define	MESHX_VND_MODEL_CID_MESHX   0x02E5
#define	MESHX_MODEL_ID_CONFIG_SRV   0x0000
#define	MESHX_MODEL_ID_CONFIG_CLI   0x0001
#define	MESHX_MODEL_ID_HEALTH_SRV   0x0002
#define	MESHX_MODEL_ID_HEALTH_CLI   0x0003
#define	MESHX_MODEL_ID_RPR_SRV   0x0004
#define	MESHX_MODEL_ID_RPR_CLI   0x0005
#define	MESHX_MODEL_ID_DF_SRV   0x0006
#define	MESHX_MODEL_ID_DF_CLI   0x0007
#define	MESHX_MODEL_ID_BRC_SRV   0x0008
#define	MESHX_MODEL_ID_BRC_CLI   0x0009
#define	MESHX_MODEL_ID_PRB_SRV   0x000A
#define	MESHX_MODEL_ID_PRB_CLI   0x000B
#define	MESHX_MODEL_ID_ODP_SRV   0x000C
#define	MESHX_MODEL_ID_ODP_CLI   0x000D
#define	MESHX_MODEL_ID_SAR_SRV   0x000E
#define	MESHX_MODEL_ID_SAR_CLI   0x000F
#define	MESHX_MODEL_ID_AGG_SRV   0x0010
#define	MESHX_MODEL_ID_AGG_CLI   0x0011
#define	MESHX_MODEL_ID_LCD_SRV   0x0012
#define	MESHX_MODEL_ID_LCD_CLI   0x0013
#define	MESHX_MODEL_ID_SRPL_SRV   0x0014
#define	MESHX_MODEL_ID_SRPL_CLI   0x0015
#define	MESHX_MODEL_ID_GEN_ONOFF_SRV   0x1000
#define	MESHX_MODEL_ID_GEN_ONOFF_CLI   0x1001
#define	MESHX_MODEL_ID_GEN_LEVEL_SRV   0x1002
#define	MESHX_MODEL_ID_GEN_LEVEL_CLI   0x1003
#define	MESHX_MODEL_ID_GEN_DEF_TRANS_TIME_SRV   0x1004
#define	MESHX_MODEL_ID_GEN_DEF_TRANS_TIME_CLI   0x1005
#define	MESHX_MODEL_ID_GEN_POWER_ONOFF_SRV   0x1006
#define	MESHX_MODEL_ID_GEN_POWER_ONOFF_SETUP_SRV   0x1007
#define	MESHX_MODEL_ID_GEN_POWER_ONOFF_CLI   0x1008
#define	MESHX_MODEL_ID_GEN_POWER_LEVEL_SRV   0x1009
#define	MESHX_MODEL_ID_GEN_POWER_LEVEL_SETUP_SRV   0x100a
#define	MESHX_MODEL_ID_GEN_POWER_LEVEL_CLI   0x100b
#define	MESHX_MODEL_ID_GEN_BATTERY_SRV   0x100c
#define	MESHX_MODEL_ID_GEN_BATTERY_CLI   0x100d
#define	MESHX_MODEL_ID_GEN_LOCATION_SRV   0x100e
#define	MESHX_MODEL_ID_GEN_LOCATION_SETUP_SRV   0x100f
#define	MESHX_MODEL_ID_GEN_LOCATION_CLI   0x1010
#define	MESHX_MODEL_ID_GEN_ADMIN_PROP_SRV   0x1011
#define	MESHX_MODEL_ID_GEN_MANUFACTURER_PROP_SRV   0x1012
#define	MESHX_MODEL_ID_GEN_USER_PROP_SRV   0x1013
#define	MESHX_MODEL_ID_GEN_CLIENT_PROP_SRV   0x1014
#define	MESHX_MODEL_ID_GEN_PROP_CLI   0x1015
#define	MESHX_MODEL_ID_SENSOR_SRV   0x1100
#define	MESHX_MODEL_ID_SENSOR_SETUP_SRV   0x1101
#define	MESHX_MODEL_ID_SENSOR_CLI   0x1102
#define	MESHX_MODEL_ID_TIME_SRV   0x1200
#define	MESHX_MODEL_ID_TIME_SETUP_SRV   0x1201
#define	MESHX_MODEL_ID_TIME_CLI   0x1202
#define	MESHX_MODEL_ID_SCENE_SRV   0x1203
#define	MESHX_MODEL_ID_SCENE_SETUP_SRV   0x1204
#define	MESHX_MODEL_ID_SCENE_CLI   0x1205
#define	MESHX_MODEL_ID_SCHEDULER_SRV   0x1206
#define	MESHX_MODEL_ID_SCHEDULER_SETUP_SRV   0x1207
#define	MESHX_MODEL_ID_SCHEDULER_CLI   0x1208
#define	MESHX_MODEL_ID_LIGHT_LIGHTNESS_SRV   0x1300
#define	MESHX_MODEL_ID_LIGHT_LIGHTNESS_SETUP_SRV   0x1301
#define	MESHX_MODEL_ID_LIGHT_LIGHTNESS_CLI   0x1302
#define	MESHX_MODEL_ID_LIGHT_CTL_SRV   0x1303
#define	MESHX_MODEL_ID_LIGHT_CTL_SETUP_SRV   0x1304
#define	MESHX_MODEL_ID_LIGHT_CTL_CLI   0x1305
#define	MESHX_MODEL_ID_LIGHT_CTL_TEMP_SRV   0x1306
#define	MESHX_MODEL_ID_LIGHT_HSL_SRV   0x1307
#define	MESHX_MODEL_ID_LIGHT_HSL_SETUP_SRV   0x1308
#define	MESHX_MODEL_ID_LIGHT_HSL_CLI   0x1309
#define	MESHX_MODEL_ID_LIGHT_HSL_HUE_SRV   0x130a
#define	MESHX_MODEL_ID_LIGHT_HSL_SAT_SRV   0x130b
#define	MESHX_MODEL_ID_LIGHT_XYL_SRV   0x130c
#define	MESHX_MODEL_ID_LIGHT_XYL_SETUP_SRV   0x130d
#define	MESHX_MODEL_ID_LIGHT_XYL_CLI   0x130e
#define	MESHX_MODEL_ID_LIGHT_LC_SRV   0x130f
#define	MESHX_MODEL_ID_LIGHT_LC_SETUP_SRV   0x1310
#define	MESHX_MODEL_ID_LIGHT_LC_CLI   0x1311
#define	MESHX_MODEL_ID_MBT_SRV   0x1400
#define	MESHX_MODEL_ID_MBT_CLI   0x1401
#define	MESHX_MODEL_OP_BEACON_GET   MESHX_MODEL_OP_2(0x80, 0x09)
#define	MESHX_MODEL_OP_COMPOSITION_DATA_GET   MESHX_MODEL_OP_2(0x80, 0x08)
#define	MESHX_MODEL_OP_DEFAULT_TTL_GET   MESHX_MODEL_OP_2(0x80, 0x0C)
#define	MESHX_MODEL_OP_GATT_PROXY_GET   MESHX_MODEL_OP_2(0x80, 0x12)
#define	MESHX_MODEL_OP_RELAY_GET   MESHX_MODEL_OP_2(0x80, 0x26)
#define	MESHX_MODEL_OP_MODEL_PUB_GET   MESHX_MODEL_OP_2(0x80, 0x18)
#define	MESHX_MODEL_OP_FRIEND_GET   MESHX_MODEL_OP_2(0x80, 0x0F)
#define	MESHX_MODEL_OP_HEARTBEAT_PUB_GET   MESHX_MODEL_OP_2(0x80, 0x38)
#define	MESHX_MODEL_OP_HEARTBEAT_SUB_GET   MESHX_MODEL_OP_2(0x80, 0x3a)
#define	MESHX_MODEL_OP_NET_KEY_GET   MESHX_MODEL_OP_2(0x80, 0x42)
#define	MESHX_MODEL_OP_APP_KEY_GET   MESHX_MODEL_OP_2(0x80, 0x01)
#define	MESHX_MODEL_OP_NODE_IDENTITY_GET   MESHX_MODEL_OP_2(0x80, 0x46)
#define	MESHX_MODEL_OP_SIG_MODEL_SUB_GET   MESHX_MODEL_OP_2(0x80, 0x29)
#define	MESHX_MODEL_OP_VENDOR_MODEL_SUB_GET   MESHX_MODEL_OP_2(0x80, 0x2B)
#define	MESHX_MODEL_OP_SIG_MODEL_APP_GET   MESHX_MODEL_OP_2(0x80, 0x4B)
#define	MESHX_MODEL_OP_VENDOR_MODEL_APP_GET   MESHX_MODEL_OP_2(0x80, 0x4D)
#define	MESHX_MODEL_OP_KEY_REFRESH_PHASE_GET   MESHX_MODEL_OP_2(0x80, 0x15)
#define	MESHX_MODEL_OP_LPN_POLLTIMEOUT_GET   MESHX_MODEL_OP_2(0x80, 0x2D)
#define	MESHX_MODEL_OP_NETWORK_TRANSMIT_GET   MESHX_MODEL_OP_2(0x80, 0x23)
#define	MESHX_MODEL_OP_BEACON_SET   MESHX_MODEL_OP_2(0x80, 0x0A)
#define	MESHX_MODEL_OP_DEFAULT_TTL_SET   MESHX_MODEL_OP_2(0x80, 0x0D)
#define	MESHX_MODEL_OP_GATT_PROXY_SET   MESHX_MODEL_OP_2(0x80, 0x13)
#define	MESHX_MODEL_OP_RELAY_SET   MESHX_MODEL_OP_2(0x80, 0x27)
#define	MESHX_MODEL_OP_MODEL_PUB_SET   MESHX_MODEL_OP_1(0x03)
#define	MESHX_MODEL_OP_MODEL_SUB_ADD   MESHX_MODEL_OP_2(0x80, 0x1B)
#define	MESHX_MODEL_OP_MODEL_SUB_VIRTUAL_ADDR_ADD   MESHX_MODEL_OP_2(0x80, 0x20)
#define	MESHX_MODEL_OP_MODEL_SUB_DELETE   MESHX_MODEL_OP_2(0x80, 0x1C)
#define	MESHX_MODEL_OP_MODEL_SUB_VIRTUAL_ADDR_DELETE   MESHX_MODEL_OP_2(0x80, 0x21)
#define	MESHX_MODEL_OP_MODEL_SUB_OVERWRITE   MESHX_MODEL_OP_2(0x80, 0x1E)
#define	MESHX_MODEL_OP_MODEL_SUB_VIRTUAL_ADDR_OVERWRITE   MESHX_MODEL_OP_2(0x80, 0x22)
#define	MESHX_MODEL_OP_NET_KEY_ADD   MESHX_MODEL_OP_2(0x80, 0x40)
#define	MESHX_MODEL_OP_APP_KEY_ADD   MESHX_MODEL_OP_1(0x00)
#define	MESHX_MODEL_OP_MODEL_APP_BIND   MESHX_MODEL_OP_2(0x80, 0x3D)
#define	MESHX_MODEL_OP_NODE_RESET   MESHX_MODEL_OP_2(0x80, 0x49)
#define	MESHX_MODEL_OP_FRIEND_SET   MESHX_MODEL_OP_2(0x80, 0x10)
#define	MESHX_MODEL_OP_HEARTBEAT_PUB_SET   MESHX_MODEL_OP_2(0x80, 0x39)
#define	MESHX_MODEL_OP_HEARTBEAT_SUB_SET   MESHX_MODEL_OP_2(0x80, 0x3B)
#define	MESHX_MODEL_OP_NET_KEY_UPDATE   MESHX_MODEL_OP_2(0x80, 0x45)
#define	MESHX_MODEL_OP_NET_KEY_DELETE   MESHX_MODEL_OP_2(0x80, 0x41)
#define	MESHX_MODEL_OP_APP_KEY_UPDATE   MESHX_MODEL_OP_1(0x01)
#define	MESHX_MODEL_OP_APP_KEY_DELETE   MESHX_MODEL_OP_2(0x80, 0x00)
#define	MESHX_MODEL_OP_NODE_IDENTITY_SET   MESHX_MODEL_OP_2(0x80, 0x47)
#define	MESHX_MODEL_OP_KEY_REFRESH_PHASE_SET   MESHX_MODEL_OP_2(0x80, 0x16)
#define	MESHX_MODEL_OP_MODEL_PUB_VIRTUAL_ADDR_SET   MESHX_MODEL_OP_2(0x80, 0x1A)
#define	MESHX_MODEL_OP_MODEL_SUB_DELETE_ALL   MESHX_MODEL_OP_2(0x80, 0x1D)
#define	MESHX_MODEL_OP_MODEL_APP_UNBIND   MESHX_MODEL_OP_2(0x80, 0x3F)
#define	MESHX_MODEL_OP_NETWORK_TRANSMIT_SET   MESHX_MODEL_OP_2(0x80, 0x24)
#define	MESHX_MODEL_OP_BEACON_STATUS   MESHX_MODEL_OP_2(0x80, 0x0B)
#define	MESHX_MODEL_OP_COMPOSITION_DATA_STATUS   MESHX_MODEL_OP_1(0x02)
#define	MESHX_MODEL_OP_DEFAULT_TTL_STATUS   MESHX_MODEL_OP_2(0x80, 0x0E)
#define	MESHX_MODEL_OP_GATT_PROXY_STATUS   MESHX_MODEL_OP_2(0x80, 0x14)
#define	MESHX_MODEL_OP_RELAY_STATUS   MESHX_MODEL_OP_2(0x80, 0x28)
#define	MESHX_MODEL_OP_MODEL_PUB_STATUS   MESHX_MODEL_OP_2(0x80, 0x19)
#define	MESHX_MODEL_OP_MODEL_SUB_STATUS   MESHX_MODEL_OP_2(0x80, 0x1F)
#define	MESHX_MODEL_OP_SIG_MODEL_SUB_LIST   MESHX_MODEL_OP_2(0x80, 0x2A)
#define	MESHX_MODEL_OP_VENDOR_MODEL_SUB_LIST   MESHX_MODEL_OP_2(0x80, 0x2C)
#define	MESHX_MODEL_OP_NET_KEY_STATUS   MESHX_MODEL_OP_2(0x80, 0x44)
#define	MESHX_MODEL_OP_NET_KEY_LIST   MESHX_MODEL_OP_2(0x80, 0x43)
#define	MESHX_MODEL_OP_APP_KEY_STATUS   MESHX_MODEL_OP_2(0x80, 0x03)
#define	MESHX_MODEL_OP_APP_KEY_LIST   MESHX_MODEL_OP_2(0x80, 0x02)
#define	MESHX_MODEL_OP_NODE_IDENTITY_STATUS   MESHX_MODEL_OP_2(0x80, 0x48)
#define	MESHX_MODEL_OP_MODEL_APP_STATUS   MESHX_MODEL_OP_2(0x80, 0x3E)
#define	MESHX_MODEL_OP_SIG_MODEL_APP_LIST   MESHX_MODEL_OP_2(0x80, 0x4C)
#define	MESHX_MODEL_OP_VENDOR_MODEL_APP_LIST   MESHX_MODEL_OP_2(0x80, 0x4E)
#define	MESHX_MODEL_OP_NODE_RESET_STATUS   MESHX_MODEL_OP_2(0x80, 0x4A)
#define	MESHX_MODEL_OP_FRIEND_STATUS   MESHX_MODEL_OP_2(0x80, 0x11)
#define	MESHX_MODEL_OP_KEY_REFRESH_PHASE_STATUS   MESHX_MODEL_OP_2(0x80, 0x17)
#define	MESHX_MODEL_OP_HEARTBEAT_PUB_STATUS   MESHX_MODEL_OP_1(0x06)
#define	MESHX_MODEL_OP_HEARTBEAT_SUB_STATUS   MESHX_MODEL_OP_2(0x80, 0x3C)
#define	MESHX_MODEL_OP_LPN_POLLTIMEOUT_STATUS   MESHX_MODEL_OP_2(0x80, 0x2E)
#define	MESHX_MODEL_OP_NETWORK_TRANSMIT_STATUS   MESHX_MODEL_OP_2(0x80, 0x25)
#define	MESHX_CFG_STATUS_SUCCESS   0x00
#define	MESHX_CFG_STATUS_INVALID_ADDRESS   0x01
#define	MESHX_CFG_STATUS_INVALID_MODEL   0x02
#define	MESHX_CFG_STATUS_INVALID_APPKEY   0x03
#define	MESHX_CFG_STATUS_INVALID_NETKEY   0x04
#define	MESHX_CFG_STATUS_INSUFFICIENT_RESOURCES   0x05
#define	MESHX_CFG_STATUS_KEY_INDEX_ALREADY_STORED   0x06
#define	MESHX_CFG_STATUS_INVALID_PUBLISH_PARAMETERS   0x07
#define	MESHX_CFG_STATUS_NOT_A_SUBSCRIBE_MODEL   0x08
#define	MESHX_CFG_STATUS_STORAGE_FAILURE   0x09
#define	MESHX_CFG_STATUS_FEATURE_NOT_SUPPORTED   0x0A
#define	MESHX_CFG_STATUS_CANNOT_UPDATE   0x0B
#define	MESHX_CFG_STATUS_CANNOT_REMOVE   0x0C
#define	MESHX_CFG_STATUS_CANNOT_BIND   0x0D
#define	MESHX_CFG_STATUS_TEMP_UNABLE_TO_CHANGE_STATE   0x0E
#define	MESHX_CFG_STATUS_CANNOT_SET   0x0F
#define	MESHX_CFG_STATUS_UNSPECIFIED_ERROR   0x10
#define	MESHX_CFG_STATUS_INVALID_BINDING   0x11
#define	MESHX_CFG_STATUS_INVALID_PATH_ENTRY   0x12
#define	MESHX_CFG_STATUS_CANNOT_GET   0x13
#define	MESHX_CFG_STATUS_OBSOLETE_INFO   0x14
#define	MESHX_CFG_STATUS_INVALID_BEARER   0x15
#define	MESHX_MODEL_OP_HEALTH_FAULT_GET   MESHX_MODEL_OP_2(0x80, 0x31)
#define	MESHX_MODEL_OP_HEALTH_PERIOD_GET   MESHX_MODEL_OP_2(0x80, 0x34)
#define	MESHX_MODEL_OP_ATTENTION_GET   MESHX_MODEL_OP_2(0x80, 0x04)
#define	MESHX_MODEL_OP_HEALTH_FAULT_CLEAR   MESHX_MODEL_OP_2(0x80, 0x2F)
#define	MESHX_MODEL_OP_HEALTH_FAULT_CLEAR_UNACK   MESHX_MODEL_OP_2(0x80, 0x30)
#define	MESHX_MODEL_OP_HEALTH_FAULT_TEST   MESHX_MODEL_OP_2(0x80, 0x32)
#define	MESHX_MODEL_OP_HEALTH_FAULT_TEST_UNACK   MESHX_MODEL_OP_2(0x80, 0x33)
#define	MESHX_MODEL_OP_HEALTH_PERIOD_SET   MESHX_MODEL_OP_2(0x80, 0x35)
#define	MESHX_MODEL_OP_HEALTH_PERIOD_SET_UNACK   MESHX_MODEL_OP_2(0x80, 0x36)
#define	MESHX_MODEL_OP_ATTENTION_SET   MESHX_MODEL_OP_2(0x80, 0x05)
#define	MESHX_MODEL_OP_ATTENTION_SET_UNACK   MESHX_MODEL_OP_2(0x80, 0x06)
#define	MESHX_MODEL_OP_HEALTH_CURRENT_STATUS   MESHX_MODEL_OP_1(0x04)
#define	MESHX_MODEL_OP_HEALTH_FAULT_STATUS   MESHX_MODEL_OP_1(0x05)
#define	MESHX_MODEL_OP_HEALTH_PERIOD_STATUS   MESHX_MODEL_OP_2(0x80, 0x37)
#define	MESHX_MODEL_OP_ATTENTION_STATUS   MESHX_MODEL_OP_2(0x80, 0x07)
#define	MESHX_MODEL_OP_GEN_ONOFF_GET   MESHX_MODEL_OP_2(0x82, 0x01)
#define	MESHX_MODEL_OP_GEN_ONOFF_SET   MESHX_MODEL_OP_2(0x82, 0x02)
#define	MESHX_MODEL_OP_GEN_ONOFF_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x03)
#define	MESHX_MODEL_OP_GEN_ONOFF_STATUS   MESHX_MODEL_OP_2(0x82, 0x04)
#define	MESHX_MODEL_OP_GEN_LEVEL_GET   MESHX_MODEL_OP_2(0x82, 0x05)
#define	MESHX_MODEL_OP_GEN_LEVEL_SET   MESHX_MODEL_OP_2(0x82, 0x06)
#define	MESHX_MODEL_OP_GEN_LEVEL_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x07)
#define	MESHX_MODEL_OP_GEN_LEVEL_STATUS   MESHX_MODEL_OP_2(0x82, 0x08)
#define	MESHX_MODEL_OP_GEN_DELTA_SET   MESHX_MODEL_OP_2(0x82, 0x09)
#define	MESHX_MODEL_OP_GEN_DELTA_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x0A)
#define	MESHX_MODEL_OP_GEN_MOVE_SET   MESHX_MODEL_OP_2(0x82, 0x0B)
#define	MESHX_MODEL_OP_GEN_MOVE_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x0C)
#define	MESHX_MODEL_OP_GEN_DEF_TRANS_TIME_GET   MESHX_MODEL_OP_2(0x82, 0x0D)
#define	MESHX_MODEL_OP_GEN_DEF_TRANS_TIME_SET   MESHX_MODEL_OP_2(0x82, 0x0E)
#define	MESHX_MODEL_OP_GEN_DEF_TRANS_TIME_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x0F)
#define	MESHX_MODEL_OP_GEN_DEF_TRANS_TIME_STATUS   MESHX_MODEL_OP_2(0x82, 0x10)
#define	MESHX_MODEL_OP_GEN_ONPOWERUP_GET   MESHX_MODEL_OP_2(0x82, 0x11)
#define	MESHX_MODEL_OP_GEN_ONPOWERUP_STATUS   MESHX_MODEL_OP_2(0x82, 0x12)
#define	MESHX_MODEL_OP_GEN_ONPOWERUP_SET   MESHX_MODEL_OP_2(0x82, 0x13)
#define	MESHX_MODEL_OP_GEN_ONPOWERUP_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x14)
#define	MESHX_MODEL_OP_GEN_POWER_LEVEL_GET   MESHX_MODEL_OP_2(0x82, 0x15)
#define	MESHX_MODEL_OP_GEN_POWER_LEVEL_SET   MESHX_MODEL_OP_2(0x82, 0x16)
#define	MESHX_MODEL_OP_GEN_POWER_LEVEL_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x17)
#define	MESHX_MODEL_OP_GEN_POWER_LEVEL_STATUS   MESHX_MODEL_OP_2(0x82, 0x18)
#define	MESHX_MODEL_OP_GEN_POWER_LAST_GET   MESHX_MODEL_OP_2(0x82, 0x19)
#define	MESHX_MODEL_OP_GEN_POWER_LAST_STATUS   MESHX_MODEL_OP_2(0x82, 0x1A)
#define	MESHX_MODEL_OP_GEN_POWER_DEFAULT_GET   MESHX_MODEL_OP_2(0x82, 0x1B)
#define	MESHX_MODEL_OP_GEN_POWER_DEFAULT_STATUS   MESHX_MODEL_OP_2(0x82, 0x1C)
#define	MESHX_MODEL_OP_GEN_POWER_RANGE_GET   MESHX_MODEL_OP_2(0x82, 0x1D)
#define	MESHX_MODEL_OP_GEN_POWER_RANGE_STATUS   MESHX_MODEL_OP_2(0x82, 0x1E)
#define	MESHX_MODEL_OP_GEN_POWER_DEFAULT_SET   MESHX_MODEL_OP_2(0x82, 0x1F)
#define	MESHX_MODEL_OP_GEN_POWER_DEFAULT_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x20)
#define	MESHX_MODEL_OP_GEN_POWER_RANGE_SET   MESHX_MODEL_OP_2(0x82, 0x21)
#define	MESHX_MODEL_OP_GEN_POWER_RANGE_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x22)
#define	MESHX_MODEL_OP_GEN_BATTERY_GET   MESHX_MODEL_OP_2(0x82, 0x23)
#define	MESHX_MODEL_OP_GEN_BATTERY_STATUS   MESHX_MODEL_OP_2(0x82, 0x24)
#define	MESHX_MODEL_OP_GEN_LOC_GLOBAL_GET   MESHX_MODEL_OP_2(0x82, 0x25)
#define	MESHX_MODEL_OP_GEN_LOC_GLOBAL_STATUS   MESHX_MODEL_OP_1(0x40)
#define	MESHX_MODEL_OP_GEN_LOC_LOCAL_GET   MESHX_MODEL_OP_2(0x82, 0x26)
#define	MESHX_MODEL_OP_GEN_LOC_LOCAL_STATUS   MESHX_MODEL_OP_2(0x82, 0x27)
#define	MESHX_MODEL_OP_GEN_LOC_GLOBAL_SET   MESHX_MODEL_OP_1(0x41)
#define	MESHX_MODEL_OP_GEN_LOC_GLOBAL_SET_UNACK   MESHX_MODEL_OP_1(0x42)
#define	MESHX_MODEL_OP_GEN_LOC_LOCAL_SET   MESHX_MODEL_OP_2(0x82, 0x28)
#define	MESHX_MODEL_OP_GEN_LOC_LOCAL_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x29)
#define	MESHX_MODEL_OP_GEN_MANUFACTURER_PROPERTIES_GET   MESHX_MODEL_OP_2(0x82, 0x2A)
#define	MESHX_MODEL_OP_GEN_MANUFACTURER_PROPERTIES_STATUS   MESHX_MODEL_OP_1(0x43)
#define	MESHX_MODEL_OP_GEN_MANUFACTURER_PROPERTY_GET   MESHX_MODEL_OP_2(0x82, 0x2B)
#define	MESHX_MODEL_OP_GEN_MANUFACTURER_PROPERTY_SET   MESHX_MODEL_OP_1(0x44)
#define	MESHX_MODEL_OP_GEN_MANUFACTURER_PROPERTY_SET_UNACK   MESHX_MODEL_OP_1(0x45)
#define	MESHX_MODEL_OP_GEN_MANUFACTURER_PROPERTY_STATUS   MESHX_MODEL_OP_1(0x46)
#define	MESHX_MODEL_OP_GEN_ADMIN_PROPERTIES_GET   MESHX_MODEL_OP_2(0x82, 0x2C)
#define	MESHX_MODEL_OP_GEN_ADMIN_PROPERTIES_STATUS   MESHX_MODEL_OP_1(0x47)
#define	MESHX_MODEL_OP_GEN_ADMIN_PROPERTY_GET   MESHX_MODEL_OP_2(0x82, 0x2D)
#define	MESHX_MODEL_OP_GEN_ADMIN_PROPERTY_SET   MESHX_MODEL_OP_1(0x48)
#define	MESHX_MODEL_OP_GEN_ADMIN_PROPERTY_SET_UNACK   MESHX_MODEL_OP_1(0x49)
#define	MESHX_MODEL_OP_GEN_ADMIN_PROPERTY_STATUS   MESHX_MODEL_OP_1(0x4A)
#define	MESHX_MODEL_OP_GEN_USER_PROPERTIES_GET   MESHX_MODEL_OP_2(0x82, 0x2E)
#define	MESHX_MODEL_OP_GEN_USER_PROPERTIES_STATUS   MESHX_MODEL_OP_1(0x4B)
#define	MESHX_MODEL_OP_GEN_USER_PROPERTY_GET   MESHX_MODEL_OP_2(0x82, 0x2F)
#define	MESHX_MODEL_OP_GEN_USER_PROPERTY_SET   MESHX_MODEL_OP_1(0x4C)
#define	MESHX_MODEL_OP_GEN_USER_PROPERTY_SET_UNACK   MESHX_MODEL_OP_1(0x4D)
#define	MESHX_MODEL_OP_GEN_USER_PROPERTY_STATUS   MESHX_MODEL_OP_1(0x4E)
#define	MESHX_MODEL_OP_GEN_CLIENT_PROPERTIES_GET   MESHX_MODEL_OP_1(0x4F)
#define	MESHX_MODEL_OP_GEN_CLIENT_PROPERTIES_STATUS   MESHX_MODEL_OP_1(0x50)
#define	MESHX_MODEL_OP_SENSOR_DESCRIPTOR_GET   MESHX_MODEL_OP_2(0x82, 0x30)
#define	MESHX_MODEL_OP_SENSOR_DESCRIPTOR_STATUS   MESHX_MODEL_OP_1(0x51)
#define	MESHX_MODEL_OP_SENSOR_GET   MESHX_MODEL_OP_2(0x82, 0x31)
#define	MESHX_MODEL_OP_SENSOR_STATUS   MESHX_MODEL_OP_1(0x52)
#define	MESHX_MODEL_OP_SENSOR_COLUMN_GET   MESHX_MODEL_OP_2(0x82, 0x32)
#define	MESHX_MODEL_OP_SENSOR_COLUMN_STATUS   MESHX_MODEL_OP_1(0x53)
#define	MESHX_MODEL_OP_SENSOR_SERIES_GET   MESHX_MODEL_OP_2(0x82, 0x33)
#define	MESHX_MODEL_OP_SENSOR_SERIES_STATUS   MESHX_MODEL_OP_1(0x54)
#define	MESHX_MODEL_OP_SENSOR_CADENCE_GET   MESHX_MODEL_OP_2(0x82, 0x34)
#define	MESHX_MODEL_OP_SENSOR_CADENCE_SET   MESHX_MODEL_OP_1(0x55)
#define	MESHX_MODEL_OP_SENSOR_CADENCE_SET_UNACK   MESHX_MODEL_OP_1(0x56)
#define	MESHX_MODEL_OP_SENSOR_CADENCE_STATUS   MESHX_MODEL_OP_1(0x57)
#define	MESHX_MODEL_OP_SENSOR_SETTINGS_GET   MESHX_MODEL_OP_2(0x82, 0x35)
#define	MESHX_MODEL_OP_SENSOR_SETTINGS_STATUS   MESHX_MODEL_OP_1(0x58)
#define	MESHX_MODEL_OP_SENSOR_SETTING_GET   MESHX_MODEL_OP_2(0x82, 0x36)
#define	MESHX_MODEL_OP_SENSOR_SETTING_SET   MESHX_MODEL_OP_1(0x59)
#define	MESHX_MODEL_OP_SENSOR_SETTING_SET_UNACK   MESHX_MODEL_OP_1(0x5A)
#define	MESHX_MODEL_OP_SENSOR_SETTING_STATUS   MESHX_MODEL_OP_1(0x5B)
#define	MESHX_MODEL_OP_TIME_GET   MESHX_MODEL_OP_2(0x82, 0x37)
#define	MESHX_MODEL_OP_TIME_SET   MESHX_MODEL_OP_1(0x5C)
#define	MESHX_MODEL_OP_TIME_STATUS   MESHX_MODEL_OP_1(0x5D)
#define	MESHX_MODEL_OP_TIME_ROLE_GET   MESHX_MODEL_OP_2(0x82, 0x38)
#define	MESHX_MODEL_OP_TIME_ROLE_SET   MESHX_MODEL_OP_2(0x82, 0x39)
#define	MESHX_MODEL_OP_TIME_ROLE_STATUS   MESHX_MODEL_OP_2(0x82, 0x3A)
#define	MESHX_MODEL_OP_TIME_ZONE_GET   MESHX_MODEL_OP_2(0x82, 0x3B)
#define	MESHX_MODEL_OP_TIME_ZONE_SET   MESHX_MODEL_OP_2(0x82, 0x3C)
#define	MESHX_MODEL_OP_TIME_ZONE_STATUS   MESHX_MODEL_OP_2(0x82, 0x3D)
#define	MESHX_MODEL_OP_TAI_UTC_DELTA_GET   MESHX_MODEL_OP_2(0x82, 0x3E)
#define	MESHX_MODEL_OP_TAI_UTC_DELTA_SET   MESHX_MODEL_OP_2(0x82, 0x3F)
#define	MESHX_MODEL_OP_TAI_UTC_DELTA_STATUS   MESHX_MODEL_OP_2(0x82, 0x40)
#define	MESHX_MODEL_OP_SCENE_GET   MESHX_MODEL_OP_2(0x82, 0x41)
#define	MESHX_MODEL_OP_SCENE_RECALL   MESHX_MODEL_OP_2(0x82, 0x42)
#define	MESHX_MODEL_OP_SCENE_RECALL_UNACK   MESHX_MODEL_OP_2(0x82, 0x43)
#define	MESHX_MODEL_OP_SCENE_STATUS   MESHX_MODEL_OP_1(0x5E)
#define	MESHX_MODEL_OP_SCENE_REGISTER_GET   MESHX_MODEL_OP_2(0x82, 0x44)
#define	MESHX_MODEL_OP_SCENE_REGISTER_STATUS   MESHX_MODEL_OP_2(0x82, 0x45)
#define	MESHX_MODEL_OP_SCENE_STORE   MESHX_MODEL_OP_2(0x82, 0x46)
#define	MESHX_MODEL_OP_SCENE_STORE_UNACK   MESHX_MODEL_OP_2(0x82, 0x47)
#define	MESHX_MODEL_OP_SCENE_DELETE   MESHX_MODEL_OP_2(0x82, 0x9E)
#define	MESHX_MODEL_OP_SCENE_DELETE_UNACK   MESHX_MODEL_OP_2(0x82, 0x9F)
#define	MESHX_MODEL_OP_SCHEDULER_ACT_GET   MESHX_MODEL_OP_2(0x82, 0x48)
#define	MESHX_MODEL_OP_SCHEDULER_ACT_STATUS   MESHX_MODEL_OP_1(0x5F)
#define	MESHX_MODEL_OP_SCHEDULER_GET   MESHX_MODEL_OP_2(0x82, 0x49)
#define	MESHX_MODEL_OP_SCHEDULER_STATUS   MESHX_MODEL_OP_2(0x82, 0x4A)
#define	MESHX_MODEL_OP_SCHEDULER_ACT_SET   MESHX_MODEL_OP_1(0x60)
#define	MESHX_MODEL_OP_SCHEDULER_ACT_SET_UNACK   MESHX_MODEL_OP_1(0x61)
#define	MESHX_MODEL_OP_LIGHT_LIGHTNESS_GET   MESHX_MODEL_OP_2(0x82, 0x4B)
#define	MESHX_MODEL_OP_LIGHT_LIGHTNESS_SET   MESHX_MODEL_OP_2(0x82, 0x4C)
#define	MESHX_MODEL_OP_LIGHT_LIGHTNESS_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x4D)
#define	MESHX_MODEL_OP_LIGHT_LIGHTNESS_STATUS   MESHX_MODEL_OP_2(0x82, 0x4E)
#define	MESHX_MODEL_OP_LIGHT_LIGHTNESS_LINEAR_GET   MESHX_MODEL_OP_2(0x82, 0x4F)
#define	MESHX_MODEL_OP_LIGHT_LIGHTNESS_LINEAR_SET   MESHX_MODEL_OP_2(0x82, 0x50)
#define	MESHX_MODEL_OP_LIGHT_LIGHTNESS_LINEAR_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x51)
#define	MESHX_MODEL_OP_LIGHT_LIGHTNESS_LINEAR_STATUS   MESHX_MODEL_OP_2(0x82, 0x52)
#define	MESHX_MODEL_OP_LIGHT_LIGHTNESS_LAST_GET   MESHX_MODEL_OP_2(0x82, 0x53)
#define	MESHX_MODEL_OP_LIGHT_LIGHTNESS_LAST_STATUS   MESHX_MODEL_OP_2(0x82, 0x54)
#define	MESHX_MODEL_OP_LIGHT_LIGHTNESS_DEFAULT_GET   MESHX_MODEL_OP_2(0x82, 0x55)
#define	MESHX_MODEL_OP_LIGHT_LIGHTNESS_DEFAULT_STATUS   MESHX_MODEL_OP_2(0x82, 0x56)
#define	MESHX_MODEL_OP_LIGHT_LIGHTNESS_RANGE_GET   MESHX_MODEL_OP_2(0x82, 0x57)
#define	MESHX_MODEL_OP_LIGHT_LIGHTNESS_RANGE_STATUS   MESHX_MODEL_OP_2(0x82, 0x58)
#define	MESHX_MODEL_OP_LIGHT_LIGHTNESS_DEFAULT_SET   MESHX_MODEL_OP_2(0x82, 0x59)
#define	MESHX_MODEL_OP_LIGHT_LIGHTNESS_DEFAULT_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x5A)
#define	MESHX_MODEL_OP_LIGHT_LIGHTNESS_RANGE_SET   MESHX_MODEL_OP_2(0x82, 0x5B)
#define	MESHX_MODEL_OP_LIGHT_LIGHTNESS_RANGE_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x5C)
#define	MESHX_MODEL_OP_LIGHT_CTL_GET   MESHX_MODEL_OP_2(0x82, 0x5D)
#define	MESHX_MODEL_OP_LIGHT_CTL_SET   MESHX_MODEL_OP_2(0x82, 0x5E)
#define	MESHX_MODEL_OP_LIGHT_CTL_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x5F)
#define	MESHX_MODEL_OP_LIGHT_CTL_STATUS   MESHX_MODEL_OP_2(0x82, 0x60)
#define	MESHX_MODEL_OP_LIGHT_CTL_TEMPERATURE_GET   MESHX_MODEL_OP_2(0x82, 0x61)
#define	MESHX_MODEL_OP_LIGHT_CTL_TEMPERATURE_RANGE_GET   MESHX_MODEL_OP_2(0x82, 0x62)
#define	MESHX_MODEL_OP_LIGHT_CTL_TEMPERATURE_RANGE_STATUS   MESHX_MODEL_OP_2(0x82, 0x63)
#define	MESHX_MODEL_OP_LIGHT_CTL_TEMPERATURE_SET   MESHX_MODEL_OP_2(0x82, 0x64)
#define	MESHX_MODEL_OP_LIGHT_CTL_TEMPERATURE_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x65)
#define	MESHX_MODEL_OP_LIGHT_CTL_TEMPERATURE_STATUS   MESHX_MODEL_OP_2(0x82, 0x66)
#define	MESHX_MODEL_OP_LIGHT_CTL_DEFAULT_GET   MESHX_MODEL_OP_2(0x82, 0x67)
#define	MESHX_MODEL_OP_LIGHT_CTL_DEFAULT_STATUS   MESHX_MODEL_OP_2(0x82, 0x68)
#define	MESHX_MODEL_OP_LIGHT_CTL_DEFAULT_SET   MESHX_MODEL_OP_2(0x82, 0x69)
#define	MESHX_MODEL_OP_LIGHT_CTL_DEFAULT_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x6A)
#define	MESHX_MODEL_OP_LIGHT_CTL_TEMPERATURE_RANGE_SET   MESHX_MODEL_OP_2(0x82, 0x6B)
#define	MESHX_MODEL_OP_LIGHT_CTL_TEMPERATURE_RANGE_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x6C)
#define	MESHX_MODEL_OP_LIGHT_HSL_GET   MESHX_MODEL_OP_2(0x82, 0x6D)
#define	MESHX_MODEL_OP_LIGHT_HSL_HUE_GET   MESHX_MODEL_OP_2(0x82, 0x6E)
#define	MESHX_MODEL_OP_LIGHT_HSL_HUE_SET   MESHX_MODEL_OP_2(0x82, 0x6F)
#define	MESHX_MODEL_OP_LIGHT_HSL_HUE_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x70)
#define	MESHX_MODEL_OP_LIGHT_HSL_HUE_STATUS   MESHX_MODEL_OP_2(0x82, 0x71)
#define	MESHX_MODEL_OP_LIGHT_HSL_SATURATION_GET   MESHX_MODEL_OP_2(0x82, 0x72)
#define	MESHX_MODEL_OP_LIGHT_HSL_SATURATION_SET   MESHX_MODEL_OP_2(0x82, 0x73)
#define	MESHX_MODEL_OP_LIGHT_HSL_SATURATION_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x74)
#define	MESHX_MODEL_OP_LIGHT_HSL_SATURATION_STATUS   MESHX_MODEL_OP_2(0x82, 0x75)
#define	MESHX_MODEL_OP_LIGHT_HSL_SET   MESHX_MODEL_OP_2(0x82, 0x76)
#define	MESHX_MODEL_OP_LIGHT_HSL_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x77)
#define	MESHX_MODEL_OP_LIGHT_HSL_STATUS   MESHX_MODEL_OP_2(0x82, 0x78)
#define	MESHX_MODEL_OP_LIGHT_HSL_TARGET_GET   MESHX_MODEL_OP_2(0x82, 0x79)
#define	MESHX_MODEL_OP_LIGHT_HSL_TARGET_STATUS   MESHX_MODEL_OP_2(0x82, 0x7A)
#define	MESHX_MODEL_OP_LIGHT_HSL_DEFAULT_GET   MESHX_MODEL_OP_2(0x82, 0x7B)
#define	MESHX_MODEL_OP_LIGHT_HSL_DEFAULT_STATUS   MESHX_MODEL_OP_2(0x82, 0x7C)
#define	MESHX_MODEL_OP_LIGHT_HSL_RANGE_GET   MESHX_MODEL_OP_2(0x82, 0x7D)
#define	MESHX_MODEL_OP_LIGHT_HSL_RANGE_STATUS   MESHX_MODEL_OP_2(0x82, 0x7E)
#define	MESHX_MODEL_OP_LIGHT_HSL_DEFAULT_SET   MESHX_MODEL_OP_2(0x82, 0x7F)
#define	MESHX_MODEL_OP_LIGHT_HSL_DEFAULT_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x80)
#define	MESHX_MODEL_OP_LIGHT_HSL_RANGE_SET   MESHX_MODEL_OP_2(0x82, 0x81)
#define	MESHX_MODEL_OP_LIGHT_HSL_RANGE_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x82)
#define	MESHX_MODEL_OP_LIGHT_XYL_GET   MESHX_MODEL_OP_2(0x82, 0x83)
#define	MESHX_MODEL_OP_LIGHT_XYL_SET   MESHX_MODEL_OP_2(0x82, 0x84)
#define	MESHX_MODEL_OP_LIGHT_XYL_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x85)
#define	MESHX_MODEL_OP_LIGHT_XYL_STATUS   MESHX_MODEL_OP_2(0x82, 0x86)
#define	MESHX_MODEL_OP_LIGHT_XYL_TARGET_GET   MESHX_MODEL_OP_2(0x82, 0x87)
#define	MESHX_MODEL_OP_LIGHT_XYL_TARGET_STATUS   MESHX_MODEL_OP_2(0x82, 0x88)
#define	MESHX_MODEL_OP_LIGHT_XYL_DEFAULT_GET   MESHX_MODEL_OP_2(0x82, 0x89)
#define	MESHX_MODEL_OP_LIGHT_XYL_DEFAULT_STATUS   MESHX_MODEL_OP_2(0x82, 0x8A)
#define	MESHX_MODEL_OP_LIGHT_XYL_RANGE_GET   MESHX_MODEL_OP_2(0x82, 0x8B)
#define	MESHX_MODEL_OP_LIGHT_XYL_RANGE_STATUS   MESHX_MODEL_OP_2(0x82, 0x8C)
#define	MESHX_MODEL_OP_LIGHT_XYL_DEFAULT_SET   MESHX_MODEL_OP_2(0x82, 0x8D)
#define	MESHX_MODEL_OP_LIGHT_XYL_DEFAULT_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x8E)
#define	MESHX_MODEL_OP_LIGHT_XYL_RANGE_SET   MESHX_MODEL_OP_2(0x82, 0x8F)
#define	MESHX_MODEL_OP_LIGHT_XYL_RANGE_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x90)
#define	MESHX_MODEL_OP_LIGHT_LC_MODE_GET   MESHX_MODEL_OP_2(0x82, 0x91)
#define	MESHX_MODEL_OP_LIGHT_LC_MODE_SET   MESHX_MODEL_OP_2(0x82, 0x92)
#define	MESHX_MODEL_OP_LIGHT_LC_MODE_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x93)
#define	MESHX_MODEL_OP_LIGHT_LC_MODE_STATUS   MESHX_MODEL_OP_2(0x82, 0x94)
#define	MESHX_MODEL_OP_LIGHT_LC_OM_GET   MESHX_MODEL_OP_2(0x82, 0x95)
#define	MESHX_MODEL_OP_LIGHT_LC_OM_SET   MESHX_MODEL_OP_2(0x82, 0x96)
#define	MESHX_MODEL_OP_LIGHT_LC_OM_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x97)
#define	MESHX_MODEL_OP_LIGHT_LC_OM_STATUS   MESHX_MODEL_OP_2(0x82, 0x98)
#define	MESHX_MODEL_OP_LIGHT_LC_LIGHT_ONOFF_GET   MESHX_MODEL_OP_2(0x82, 0x99)
#define	MESHX_MODEL_OP_LIGHT_LC_LIGHT_ONOFF_SET   MESHX_MODEL_OP_2(0x82, 0x9A)
#define	MESHX_MODEL_OP_LIGHT_LC_LIGHT_ONOFF_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x9B)
#define	MESHX_MODEL_OP_LIGHT_LC_LIGHT_ONOFF_STATUS   MESHX_MODEL_OP_2(0x82, 0x9C)
#define	MESHX_MODEL_OP_LIGHT_LC_PROPERTY_GET   MESHX_MODEL_OP_2(0x82, 0x9D)
#define	MESHX_MODEL_OP_LIGHT_LC_PROPERTY_SET   MESHX_MODEL_OP_1(0x62)
#define	MESHX_MODEL_OP_LIGHT_LC_PROPERTY_SET_UNACK   MESHX_MODEL_OP_1(0x63)
#define	MESHX_MODEL_OP_LIGHT_LC_PROPERTY_STATUS   MESHX_MODEL_OP_1(0x64)
#define	MESHX_SETTINGS_UID_SIZE   20
#define	MESHX_BD_ADDR_LEN   6
#define	MESHX_UUID_ADDR_LEN   16
#define	MESHX_UUID_EMPTY   (meshx_uuid_addr_t){0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}

Typedefs
typedef void *	meshx_ptr_t
typedef const void *	meshx_cptr_t
typedef unsigned char	meshx_addr_type_t
typedef uint8_t	meshx_bd_addr_t[6]
typedef uint8_t	meshx_uuid_addr_t[16]

Enumerations
enum	meshx_prov_cb_event_t {   MESHX_PROV_REGISTER_COMP_EVT ,   MESHX_NODE_SET_UPROV_NAME_COMP_EVT ,   MESHX_NODE_PROV_ENABLE_COMP_EVT ,   MESHX_NODE_PROV_DISABLE_COMP_EVT ,   MESHX_NODE_PROV_LINK_OPEN_EVT ,   MESHX_NODE_PROV_LINK_CLOSE_EVT ,   MESHX_NODE_PROV_OOB_PUB_KEY_EVT ,   MESHX_NODE_PROV_OUTPUT_NUMBER_EVT ,   MESHX_NODE_PROV_OUTPUT_STRING_EVT ,   MESHX_NODE_PROV_INPUT_EVT ,   MESHX_NODE_PROV_COMPLETE_EVT ,   MESHX_NODE_PROV_RESET_EVT ,   MESHX_NODE_PROV_SET_OOB_PUB_KEY_COMP_EVT ,   MESHX_NODE_PROV_INPUT_NUMBER_COMP_EVT ,   MESHX_NODE_PROV_INPUT_STRING_COMP_EVT ,   MESHX_NODE_PROXY_IDENTITY_ENABLE_COMP_EVT ,   MESHX_NODE_PRIVATE_PROXY_IDENTITY_ENABLE_COMP_EVT ,   MESHX_NODE_PRIVATE_PROXY_IDENTITY_DISABLE_COMP_EVT ,   MESHX_NODE_PROXY_GATT_ENABLE_COMP_EVT ,   MESHX_NODE_PROXY_GATT_DISABLE_COMP_EVT ,   MESHX_NODE_ADD_LOCAL_NET_KEY_COMP_EVT ,   MESHX_NODE_ADD_LOCAL_APP_KEY_COMP_EVT ,   MESHX_NODE_BIND_APP_KEY_TO_MODEL_COMP_EVT ,   MESHX_PROVISIONER_PROV_ENABLE_COMP_EVT ,   MESHX_PROVISIONER_PROV_DISABLE_COMP_EVT ,   MESHX_PROVISIONER_RECV_UNPROV_ADV_PKT_EVT ,   MESHX_PROVISIONER_PROV_READ_OOB_PUB_KEY_EVT ,   MESHX_PROVISIONER_PROV_INPUT_EVT ,   MESHX_PROVISIONER_PROV_OUTPUT_EVT ,   MESHX_PROVISIONER_PROV_LINK_OPEN_EVT ,   MESHX_PROVISIONER_PROV_LINK_CLOSE_EVT ,   MESHX_PROVISIONER_PROV_COMPLETE_EVT ,   MESHX_PROVISIONER_CERT_BASED_PROV_START_EVT ,   MESHX_PROVISIONER_RECV_PROV_RECORDS_LIST_EVT ,   MESHX_PROVISIONER_PROV_RECORD_RECV_COMP_EVT ,   MESHX_PROVISIONER_SEND_PROV_RECORDS_GET_EVT ,   MESHX_PROVISIONER_SEND_PROV_RECORD_REQUEST_EVT ,   MESHX_PROVISIONER_SEND_PROV_INVITE_EVT ,   MESHX_PROVISIONER_SEND_LINK_CLOSE_EVT ,   MESHX_PROVISIONER_ADD_UNPROV_DEV_COMP_EVT ,   MESHX_PROVISIONER_PROV_DEV_WITH_ADDR_COMP_EVT ,   MESHX_PROVISIONER_DELETE_DEV_COMP_EVT ,   MESHX_PROVISIONER_SET_DEV_UUID_MATCH_COMP_EVT ,   MESHX_PROVISIONER_SET_PROV_DATA_INFO_COMP_EVT ,   MESHX_PROVISIONER_SET_STATIC_OOB_VALUE_COMP_EVT ,   MESHX_PROVISIONER_SET_PRIMARY_ELEM_ADDR_COMP_EVT ,   MESHX_PROVISIONER_PROV_READ_OOB_PUB_KEY_COMP_EVT ,   MESHX_PROVISIONER_PROV_INPUT_NUMBER_COMP_EVT ,   MESHX_PROVISIONER_PROV_INPUT_STRING_COMP_EVT ,   MESHX_PROVISIONER_SET_NODE_NAME_COMP_EVT ,   MESHX_PROVISIONER_ADD_LOCAL_APP_KEY_COMP_EVT ,   MESHX_PROVISIONER_UPDATE_LOCAL_APP_KEY_COMP_EVT ,   MESHX_PROVISIONER_BIND_APP_KEY_TO_MODEL_COMP_EVT ,   MESHX_PROVISIONER_ADD_LOCAL_NET_KEY_COMP_EVT ,   MESHX_PROVISIONER_UPDATE_LOCAL_NET_KEY_COMP_EVT ,   MESHX_PROVISIONER_STORE_NODE_COMP_DATA_COMP_EVT ,   MESHX_PROVISIONER_DELETE_NODE_WITH_UUID_COMP_EVT ,   MESHX_PROVISIONER_DELETE_NODE_WITH_ADDR_COMP_EVT ,   MESHX_PROVISIONER_ENABLE_HEARTBEAT_RECV_COMP_EVT ,   MESHX_PROVISIONER_SET_HEARTBEAT_FILTER_TYPE_COMP_EVT ,   MESHX_PROVISIONER_SET_HEARTBEAT_FILTER_INFO_COMP_EVT ,   MESHX_PROVISIONER_RECV_HEARTBEAT_MESSAGE_EVT ,   MESHX_PROVISIONER_DIRECT_ERASE_SETTINGS_COMP_EVT ,   MESHX_PROVISIONER_OPEN_SETTINGS_WITH_INDEX_COMP_EVT ,   MESHX_PROVISIONER_OPEN_SETTINGS_WITH_UID_COMP_EVT ,   MESHX_PROVISIONER_CLOSE_SETTINGS_WITH_INDEX_COMP_EVT ,   MESHX_PROVISIONER_CLOSE_SETTINGS_WITH_UID_COMP_EVT ,   MESHX_PROVISIONER_DELETE_SETTINGS_WITH_INDEX_COMP_EVT ,   MESHX_PROVISIONER_DELETE_SETTINGS_WITH_UID_COMP_EVT ,   MESHX_SET_FAST_PROV_INFO_COMP_EVT ,   MESHX_SET_FAST_PROV_ACTION_COMP_EVT ,   MESHX_HEARTBEAT_MESSAGE_RECV_EVT ,   MESHX_LPN_ENABLE_COMP_EVT ,   MESHX_LPN_DISABLE_COMP_EVT ,   MESHX_LPN_POLL_COMP_EVT ,   MESHX_LPN_FRIENDSHIP_ESTABLISH_EVT ,   MESHX_LPN_FRIENDSHIP_TERMINATE_EVT ,   MESHX_FRIEND_FRIENDSHIP_ESTABLISH_EVT ,   MESHX_FRIEND_FRIENDSHIP_TERMINATE_EVT ,   MESHX_PROXY_CLIENT_RECV_ADV_PKT_EVT ,   MESHX_PROXY_CLIENT_CONNECTED_EVT ,   MESHX_PROXY_CLIENT_DISCONNECTED_EVT ,   MESHX_PROXY_CLIENT_RECV_FILTER_STATUS_EVT ,   MESHX_PROXY_CLIENT_CONNECT_COMP_EVT ,   MESHX_PROXY_CLIENT_DISCONNECT_COMP_EVT ,   MESHX_PROXY_CLIENT_SET_FILTER_TYPE_COMP_EVT ,   MESHX_PROXY_CLIENT_ADD_FILTER_ADDR_COMP_EVT ,   MESHX_PROXY_CLIENT_REMOVE_FILTER_ADDR_COMP_EVT ,   MESHX_PROXY_CLIENT_DIRECTED_PROXY_SET_COMP_EVT ,   MESHX_PROXY_SERVER_CONNECTED_EVT ,   MESHX_PROXY_SERVER_DISCONNECTED_EVT ,   MESHX_PROXY_CLIENT_SEND_SOLIC_PDU_COMP_EVT ,   MESHX_MODEL_SUBSCRIBE_GROUP_ADDR_COMP_EVT ,   MESHX_MODEL_UNSUBSCRIBE_GROUP_ADDR_COMP_EVT ,   MESHX_DEINIT_MESH_COMP_EVT ,   MESHX_PROV_EVT_MAX }
enum	meshx_cb_type_t {   MESHX_TYPE_PROV_CB ,   MESHX_TYPE_OUTPUT_NUM_CB ,   MESHX_TYPE_OUTPUT_STR_CB ,   MESHX_TYPE_INTPUT_CB ,   MESHX_TYPE_LINK_OPEN_CB ,   MESHX_TYPE_LINK_CLOSE_CB ,   MESHX_TYPE_COMPLETE_CB ,   MESHX_TYPE_RESET_CB }
enum	meshx_oob_method_t {   MESHX_NO_OOB ,   MESHX_STATIC_OOB ,   MESHX_OUTPUT_OOB ,   MESHX_INPUT_OOB }
enum	meshx_output_action_t {   MESHX_NO_OUTPUT = 0 ,   MESHX_BLINK = (1UL << (0)) ,   MESHX_BEEP = (1UL << (1)) ,   MESHX_VIBRATE = (1UL << (2)) ,   MESHX_DISPLAY_NUMBER = (1UL << (3)) ,   MESHX_DISPLAY_STRING = (1UL << (4)) }
enum	meshx_input_action_t {   MESHX_NO_INPUT = 0 ,   MESHX_PUSH = (1UL << (0)) ,   MESHX_TWIST = (1UL << (1)) ,   MESHX_ENTER_NUMBER = (1UL << (2)) ,   MESHX_ENTER_STRING = (1UL << (3)) }

Detailed Description

Common definitions for BLE Mesh models and opcodes in the MeshX framework.

Copyright (c) 2024 - 2025 MeshX

This header file contains macros and definitions for BLE Mesh models, opcodes, and related constants used in the MeshX framework. It includes:

• Address type checks and constants.
• Model ID definitions for foundation and specification models.
• Opcode definitions for various BLE Mesh operations.
• Configuration status codes.

These definitions are used to facilitate the implementation and interaction with BLE Mesh models and their associated operations.

Note

Ensure that this file is included only once in a compilation unit by using #pragma once.

Macro Definition Documentation

MESHX_ADDR_BROADCAST

#define MESHX_ADDR_BROADCAST

(

_addr

)

Value:

(_addr == 0xFFFF)

MESHX_ADDR_GROUP_START

#define MESHX_ADDR_GROUP_START   0xC000

MESHX_ADDR_IS_GROUP

#define MESHX_ADDR_IS_GROUP

(

_addr

)

Value:

((_addr) >= 0xC000 && (_addr) <= 0xFF00)

MESHX_ADDR_IS_UNICAST

#define MESHX_ADDR_IS_UNICAST

(

_addr

)

Value:

((_addr) && (_addr) < 0x8000)

MESHX_ADDR_UNASSIGNED

#define MESHX_ADDR_UNASSIGNED   0x0000

MESHX_ARRAY_SIZE

#define MESHX_ARRAY_SIZE

(

_arr

)

Value:

(sizeof(_arr) / sizeof((_arr)[0]))

MESHX_BD_ADDR_LEN

#define MESHX_BD_ADDR_LEN   6

MESHX_BIT

#define MESHX_BIT

(

nr

)

Value:

(1UL << (nr))

MESHX_CFG_STATUS_CANNOT_BIND

#define MESHX_CFG_STATUS_CANNOT_BIND   0x0D

MESHX_CFG_STATUS_CANNOT_GET

#define MESHX_CFG_STATUS_CANNOT_GET   0x13

MESHX_CFG_STATUS_CANNOT_REMOVE

#define MESHX_CFG_STATUS_CANNOT_REMOVE   0x0C

MESHX_CFG_STATUS_CANNOT_SET

#define MESHX_CFG_STATUS_CANNOT_SET   0x0F

MESHX_CFG_STATUS_CANNOT_UPDATE

#define MESHX_CFG_STATUS_CANNOT_UPDATE   0x0B

MESHX_CFG_STATUS_FEATURE_NOT_SUPPORTED

#define MESHX_CFG_STATUS_FEATURE_NOT_SUPPORTED   0x0A

MESHX_CFG_STATUS_INSUFFICIENT_RESOURCES

#define MESHX_CFG_STATUS_INSUFFICIENT_RESOURCES   0x05

MESHX_CFG_STATUS_INVALID_ADDRESS

#define MESHX_CFG_STATUS_INVALID_ADDRESS   0x01

MESHX_CFG_STATUS_INVALID_APPKEY

#define MESHX_CFG_STATUS_INVALID_APPKEY   0x03

MESHX_CFG_STATUS_INVALID_BEARER

#define MESHX_CFG_STATUS_INVALID_BEARER   0x15

MESHX_CFG_STATUS_INVALID_BINDING

#define MESHX_CFG_STATUS_INVALID_BINDING   0x11

MESHX_CFG_STATUS_INVALID_MODEL

#define MESHX_CFG_STATUS_INVALID_MODEL   0x02

MESHX_CFG_STATUS_INVALID_NETKEY

#define MESHX_CFG_STATUS_INVALID_NETKEY   0x04

MESHX_CFG_STATUS_INVALID_PATH_ENTRY

#define MESHX_CFG_STATUS_INVALID_PATH_ENTRY   0x12

MESHX_CFG_STATUS_INVALID_PUBLISH_PARAMETERS

#define MESHX_CFG_STATUS_INVALID_PUBLISH_PARAMETERS   0x07

MESHX_CFG_STATUS_KEY_INDEX_ALREADY_STORED

#define MESHX_CFG_STATUS_KEY_INDEX_ALREADY_STORED   0x06

MESHX_CFG_STATUS_NOT_A_SUBSCRIBE_MODEL

#define MESHX_CFG_STATUS_NOT_A_SUBSCRIBE_MODEL   0x08

MESHX_CFG_STATUS_OBSOLETE_INFO

#define MESHX_CFG_STATUS_OBSOLETE_INFO   0x14

MESHX_CFG_STATUS_STORAGE_FAILURE

#define MESHX_CFG_STATUS_STORAGE_FAILURE   0x09

MESHX_CFG_STATUS_SUCCESS

#define MESHX_CFG_STATUS_SUCCESS   0x00

MESHX_CFG_STATUS_TEMP_UNABLE_TO_CHANGE_STATE

#define MESHX_CFG_STATUS_TEMP_UNABLE_TO_CHANGE_STATE   0x0E

MESHX_CFG_STATUS_UNSPECIFIED_ERROR

#define MESHX_CFG_STATUS_UNSPECIFIED_ERROR   0x10

MESHX_CID_SIG

#define MESHX_CID_SIG   0xFFFF

MESHX_KEY_UNUSED

#define MESHX_KEY_UNUSED   0XFFFF

MESHX_MODEL_ID_AGG_CLI

#define MESHX_MODEL_ID_AGG_CLI   0x0011

MESHX_MODEL_ID_AGG_SRV

#define MESHX_MODEL_ID_AGG_SRV   0x0010

MESHX_MODEL_ID_BRC_CLI

#define MESHX_MODEL_ID_BRC_CLI   0x0009

MESHX_MODEL_ID_BRC_SRV

#define MESHX_MODEL_ID_BRC_SRV   0x0008

MESHX_MODEL_ID_CONFIG_CLI

#define MESHX_MODEL_ID_CONFIG_CLI   0x0001

MESHX_MODEL_ID_CONFIG_SRV

#define MESHX_MODEL_ID_CONFIG_SRV   0x0000

MESHX_MODEL_ID_DF_CLI

#define MESHX_MODEL_ID_DF_CLI   0x0007

MESHX_MODEL_ID_DF_SRV

#define MESHX_MODEL_ID_DF_SRV   0x0006

MESHX_MODEL_ID_GEN_ADMIN_PROP_SRV

#define MESHX_MODEL_ID_GEN_ADMIN_PROP_SRV   0x1011

MESHX_MODEL_ID_GEN_BATTERY_CLI

#define MESHX_MODEL_ID_GEN_BATTERY_CLI   0x100d

MESHX_MODEL_ID_GEN_BATTERY_SRV

#define MESHX_MODEL_ID_GEN_BATTERY_SRV   0x100c

MESHX_MODEL_ID_GEN_CLIENT_PROP_SRV

#define MESHX_MODEL_ID_GEN_CLIENT_PROP_SRV   0x1014

MESHX_MODEL_ID_GEN_DEF_TRANS_TIME_CLI

#define MESHX_MODEL_ID_GEN_DEF_TRANS_TIME_CLI   0x1005

MESHX_MODEL_ID_GEN_DEF_TRANS_TIME_SRV

#define MESHX_MODEL_ID_GEN_DEF_TRANS_TIME_SRV   0x1004

MESHX_MODEL_ID_GEN_LEVEL_CLI

#define MESHX_MODEL_ID_GEN_LEVEL_CLI   0x1003

MESHX_MODEL_ID_GEN_LEVEL_SRV

#define MESHX_MODEL_ID_GEN_LEVEL_SRV   0x1002

MESHX_MODEL_ID_GEN_LOCATION_CLI

#define MESHX_MODEL_ID_GEN_LOCATION_CLI   0x1010

MESHX_MODEL_ID_GEN_LOCATION_SETUP_SRV

#define MESHX_MODEL_ID_GEN_LOCATION_SETUP_SRV   0x100f

MESHX_MODEL_ID_GEN_LOCATION_SRV

#define MESHX_MODEL_ID_GEN_LOCATION_SRV   0x100e

MESHX_MODEL_ID_GEN_MANUFACTURER_PROP_SRV

#define MESHX_MODEL_ID_GEN_MANUFACTURER_PROP_SRV   0x1012

MESHX_MODEL_ID_GEN_ONOFF_CLI

#define MESHX_MODEL_ID_GEN_ONOFF_CLI   0x1001

MESHX_MODEL_ID_GEN_ONOFF_SRV

#define MESHX_MODEL_ID_GEN_ONOFF_SRV   0x1000

MESHX_MODEL_ID_GEN_POWER_LEVEL_CLI

#define MESHX_MODEL_ID_GEN_POWER_LEVEL_CLI   0x100b

MESHX_MODEL_ID_GEN_POWER_LEVEL_SETUP_SRV

#define MESHX_MODEL_ID_GEN_POWER_LEVEL_SETUP_SRV   0x100a

MESHX_MODEL_ID_GEN_POWER_LEVEL_SRV

#define MESHX_MODEL_ID_GEN_POWER_LEVEL_SRV   0x1009

MESHX_MODEL_ID_GEN_POWER_ONOFF_CLI

#define MESHX_MODEL_ID_GEN_POWER_ONOFF_CLI   0x1008

MESHX_MODEL_ID_GEN_POWER_ONOFF_SETUP_SRV

#define MESHX_MODEL_ID_GEN_POWER_ONOFF_SETUP_SRV   0x1007

MESHX_MODEL_ID_GEN_POWER_ONOFF_SRV

#define MESHX_MODEL_ID_GEN_POWER_ONOFF_SRV   0x1006

MESHX_MODEL_ID_GEN_PROP_CLI

#define MESHX_MODEL_ID_GEN_PROP_CLI   0x1015

MESHX_MODEL_ID_GEN_USER_PROP_SRV

#define MESHX_MODEL_ID_GEN_USER_PROP_SRV   0x1013

MESHX_MODEL_ID_HEALTH_CLI

#define MESHX_MODEL_ID_HEALTH_CLI   0x0003

MESHX_MODEL_ID_HEALTH_SRV

#define MESHX_MODEL_ID_HEALTH_SRV   0x0002

MESHX_MODEL_ID_LCD_CLI

#define MESHX_MODEL_ID_LCD_CLI   0x0013

MESHX_MODEL_ID_LCD_SRV

#define MESHX_MODEL_ID_LCD_SRV   0x0012

MESHX_MODEL_ID_LIGHT_CTL_CLI

#define MESHX_MODEL_ID_LIGHT_CTL_CLI   0x1305

MESHX_MODEL_ID_LIGHT_CTL_SETUP_SRV

#define MESHX_MODEL_ID_LIGHT_CTL_SETUP_SRV   0x1304

MESHX_MODEL_ID_LIGHT_CTL_SRV

#define MESHX_MODEL_ID_LIGHT_CTL_SRV   0x1303

MESHX_MODEL_ID_LIGHT_CTL_TEMP_SRV

#define MESHX_MODEL_ID_LIGHT_CTL_TEMP_SRV   0x1306

MESHX_MODEL_ID_LIGHT_HSL_CLI

#define MESHX_MODEL_ID_LIGHT_HSL_CLI   0x1309

MESHX_MODEL_ID_LIGHT_HSL_HUE_SRV

#define MESHX_MODEL_ID_LIGHT_HSL_HUE_SRV   0x130a

MESHX_MODEL_ID_LIGHT_HSL_SAT_SRV

#define MESHX_MODEL_ID_LIGHT_HSL_SAT_SRV   0x130b

MESHX_MODEL_ID_LIGHT_HSL_SETUP_SRV

#define MESHX_MODEL_ID_LIGHT_HSL_SETUP_SRV   0x1308

MESHX_MODEL_ID_LIGHT_HSL_SRV

#define MESHX_MODEL_ID_LIGHT_HSL_SRV   0x1307

MESHX_MODEL_ID_LIGHT_LC_CLI

#define MESHX_MODEL_ID_LIGHT_LC_CLI   0x1311

MESHX_MODEL_ID_LIGHT_LC_SETUP_SRV

#define MESHX_MODEL_ID_LIGHT_LC_SETUP_SRV   0x1310

MESHX_MODEL_ID_LIGHT_LC_SRV

#define MESHX_MODEL_ID_LIGHT_LC_SRV   0x130f

MESHX_MODEL_ID_LIGHT_LIGHTNESS_CLI

#define MESHX_MODEL_ID_LIGHT_LIGHTNESS_CLI   0x1302

MESHX_MODEL_ID_LIGHT_LIGHTNESS_SETUP_SRV

#define MESHX_MODEL_ID_LIGHT_LIGHTNESS_SETUP_SRV   0x1301

MESHX_MODEL_ID_LIGHT_LIGHTNESS_SRV

#define MESHX_MODEL_ID_LIGHT_LIGHTNESS_SRV   0x1300

MESHX_MODEL_ID_LIGHT_XYL_CLI

#define MESHX_MODEL_ID_LIGHT_XYL_CLI   0x130e

MESHX_MODEL_ID_LIGHT_XYL_SETUP_SRV

#define MESHX_MODEL_ID_LIGHT_XYL_SETUP_SRV   0x130d

MESHX_MODEL_ID_LIGHT_XYL_SRV

#define MESHX_MODEL_ID_LIGHT_XYL_SRV   0x130c

MESHX_MODEL_ID_MBT_CLI

#define MESHX_MODEL_ID_MBT_CLI   0x1401

MESHX_MODEL_ID_MBT_SRV

#define MESHX_MODEL_ID_MBT_SRV   0x1400

MESHX_MODEL_ID_ODP_CLI

#define MESHX_MODEL_ID_ODP_CLI   0x000D

MESHX_MODEL_ID_ODP_SRV

#define MESHX_MODEL_ID_ODP_SRV   0x000C

MESHX_MODEL_ID_PRB_CLI

#define MESHX_MODEL_ID_PRB_CLI   0x000B

MESHX_MODEL_ID_PRB_SRV

#define MESHX_MODEL_ID_PRB_SRV   0x000A

MESHX_MODEL_ID_RPR_CLI

#define MESHX_MODEL_ID_RPR_CLI   0x0005

MESHX_MODEL_ID_RPR_SRV

#define MESHX_MODEL_ID_RPR_SRV   0x0004

MESHX_MODEL_ID_SAR_CLI

#define MESHX_MODEL_ID_SAR_CLI   0x000F

MESHX_MODEL_ID_SAR_SRV

#define MESHX_MODEL_ID_SAR_SRV   0x000E

MESHX_MODEL_ID_SCENE_CLI

#define MESHX_MODEL_ID_SCENE_CLI   0x1205

MESHX_MODEL_ID_SCENE_SETUP_SRV

#define MESHX_MODEL_ID_SCENE_SETUP_SRV   0x1204

MESHX_MODEL_ID_SCENE_SRV

#define MESHX_MODEL_ID_SCENE_SRV   0x1203

MESHX_MODEL_ID_SCHEDULER_CLI

#define MESHX_MODEL_ID_SCHEDULER_CLI   0x1208

MESHX_MODEL_ID_SCHEDULER_SETUP_SRV

#define MESHX_MODEL_ID_SCHEDULER_SETUP_SRV   0x1207

MESHX_MODEL_ID_SCHEDULER_SRV

#define MESHX_MODEL_ID_SCHEDULER_SRV   0x1206

MESHX_MODEL_ID_SENSOR_CLI

#define MESHX_MODEL_ID_SENSOR_CLI   0x1102

MESHX_MODEL_ID_SENSOR_SETUP_SRV

#define MESHX_MODEL_ID_SENSOR_SETUP_SRV   0x1101

MESHX_MODEL_ID_SENSOR_SRV

#define MESHX_MODEL_ID_SENSOR_SRV   0x1100

MESHX_MODEL_ID_SIG_START

#define MESHX_MODEL_ID_SIG_START   0x1000

BLE Mesh models related Model ID and Opcode definitions.

MESHX_MODEL_ID_SRPL_CLI

#define MESHX_MODEL_ID_SRPL_CLI   0x0015

Models from the Mesh Model Specification

MESHX_MODEL_ID_SRPL_SRV

#define MESHX_MODEL_ID_SRPL_SRV   0x0014

MESHX_MODEL_ID_TIME_CLI

#define MESHX_MODEL_ID_TIME_CLI   0x1202

MESHX_MODEL_ID_TIME_SETUP_SRV

#define MESHX_MODEL_ID_TIME_SETUP_SRV   0x1201

MESHX_MODEL_ID_TIME_SRV

#define MESHX_MODEL_ID_TIME_SRV   0x1200

MESHX_MODEL_OP_1

#define MESHX_MODEL_OP_1

(

b0

)

Value:

(b0)

MESHX_MODEL_OP_2

#define MESHX_MODEL_OP_2	(		b0,
			b1 )

Value:

(((b0) << 8) | (b1))

MESHX_MODEL_OP_3

#define MESHX_MODEL_OP_3	(		b0,
			cid )

Value:

((((b0) << 16) | 0xC00000) | (cid))

MESHX_MODEL_OP_APP_KEY_ADD

#define MESHX_MODEL_OP_APP_KEY_ADD   MESHX_MODEL_OP_1(0x00)

Config AppKey Add

MESHX_MODEL_OP_APP_KEY_DELETE

#define MESHX_MODEL_OP_APP_KEY_DELETE   MESHX_MODEL_OP_2(0x80, 0x00)

Config AppKey Delete

MESHX_MODEL_OP_APP_KEY_GET

#define MESHX_MODEL_OP_APP_KEY_GET   MESHX_MODEL_OP_2(0x80, 0x01)

Config AppKey Get

MESHX_MODEL_OP_APP_KEY_LIST

#define MESHX_MODEL_OP_APP_KEY_LIST   MESHX_MODEL_OP_2(0x80, 0x02)

MESHX_MODEL_OP_APP_KEY_STATUS

#define MESHX_MODEL_OP_APP_KEY_STATUS   MESHX_MODEL_OP_2(0x80, 0x03)

MESHX_MODEL_OP_APP_KEY_UPDATE

#define MESHX_MODEL_OP_APP_KEY_UPDATE   MESHX_MODEL_OP_1(0x01)

Config AppKey Update

MESHX_MODEL_OP_ATTENTION_GET

#define MESHX_MODEL_OP_ATTENTION_GET   MESHX_MODEL_OP_2(0x80, 0x04)

Health Attention Get

MESHX_MODEL_OP_ATTENTION_SET

#define MESHX_MODEL_OP_ATTENTION_SET   MESHX_MODEL_OP_2(0x80, 0x05)

Health Attention Set

MESHX_MODEL_OP_ATTENTION_SET_UNACK

#define MESHX_MODEL_OP_ATTENTION_SET_UNACK   MESHX_MODEL_OP_2(0x80, 0x06)

Health Attention Set Unacknowledged

MESHX_MODEL_OP_ATTENTION_STATUS

#define MESHX_MODEL_OP_ATTENTION_STATUS   MESHX_MODEL_OP_2(0x80, 0x07)

Generic OnOff Message Opcode

MESHX_MODEL_OP_BEACON_GET

#define MESHX_MODEL_OP_BEACON_GET   MESHX_MODEL_OP_2(0x80, 0x09)

Config Beacon Get

MESHX_MODEL_OP_BEACON_SET

#define MESHX_MODEL_OP_BEACON_SET   MESHX_MODEL_OP_2(0x80, 0x0A)

Config Beacon Set

MESHX_MODEL_OP_BEACON_STATUS

#define MESHX_MODEL_OP_BEACON_STATUS   MESHX_MODEL_OP_2(0x80, 0x0B)

MESHX_MODEL_OP_COMPOSITION_DATA_GET

#define MESHX_MODEL_OP_COMPOSITION_DATA_GET   MESHX_MODEL_OP_2(0x80, 0x08)

Config Composition Data Get

MESHX_MODEL_OP_COMPOSITION_DATA_STATUS

#define MESHX_MODEL_OP_COMPOSITION_DATA_STATUS   MESHX_MODEL_OP_1(0x02)

MESHX_MODEL_OP_DEFAULT_TTL_GET

#define MESHX_MODEL_OP_DEFAULT_TTL_GET   MESHX_MODEL_OP_2(0x80, 0x0C)

Config Default TTL Get

MESHX_MODEL_OP_DEFAULT_TTL_SET

#define MESHX_MODEL_OP_DEFAULT_TTL_SET   MESHX_MODEL_OP_2(0x80, 0x0D)

Config Default TTL Set

MESHX_MODEL_OP_DEFAULT_TTL_STATUS

#define MESHX_MODEL_OP_DEFAULT_TTL_STATUS   MESHX_MODEL_OP_2(0x80, 0x0E)

MESHX_MODEL_OP_FRIEND_GET

#define MESHX_MODEL_OP_FRIEND_GET   MESHX_MODEL_OP_2(0x80, 0x0F)

Config Friend Get

MESHX_MODEL_OP_FRIEND_SET

#define MESHX_MODEL_OP_FRIEND_SET   MESHX_MODEL_OP_2(0x80, 0x10)

Config Friend Set

MESHX_MODEL_OP_FRIEND_STATUS

#define MESHX_MODEL_OP_FRIEND_STATUS   MESHX_MODEL_OP_2(0x80, 0x11)

MESHX_MODEL_OP_GATT_PROXY_GET

#define MESHX_MODEL_OP_GATT_PROXY_GET   MESHX_MODEL_OP_2(0x80, 0x12)

Config GATT Proxy Get

MESHX_MODEL_OP_GATT_PROXY_SET

#define MESHX_MODEL_OP_GATT_PROXY_SET   MESHX_MODEL_OP_2(0x80, 0x13)

Config GATT Proxy Set

MESHX_MODEL_OP_GATT_PROXY_STATUS

#define MESHX_MODEL_OP_GATT_PROXY_STATUS   MESHX_MODEL_OP_2(0x80, 0x14)

MESHX_MODEL_OP_GEN_ADMIN_PROPERTIES_GET

#define MESHX_MODEL_OP_GEN_ADMIN_PROPERTIES_GET   MESHX_MODEL_OP_2(0x82, 0x2C)

MESHX_MODEL_OP_GEN_ADMIN_PROPERTIES_STATUS

#define MESHX_MODEL_OP_GEN_ADMIN_PROPERTIES_STATUS   MESHX_MODEL_OP_1(0x47)

MESHX_MODEL_OP_GEN_ADMIN_PROPERTY_GET

#define MESHX_MODEL_OP_GEN_ADMIN_PROPERTY_GET   MESHX_MODEL_OP_2(0x82, 0x2D)

MESHX_MODEL_OP_GEN_ADMIN_PROPERTY_SET

#define MESHX_MODEL_OP_GEN_ADMIN_PROPERTY_SET   MESHX_MODEL_OP_1(0x48)

MESHX_MODEL_OP_GEN_ADMIN_PROPERTY_SET_UNACK

#define MESHX_MODEL_OP_GEN_ADMIN_PROPERTY_SET_UNACK   MESHX_MODEL_OP_1(0x49)

MESHX_MODEL_OP_GEN_ADMIN_PROPERTY_STATUS

#define MESHX_MODEL_OP_GEN_ADMIN_PROPERTY_STATUS   MESHX_MODEL_OP_1(0x4A)

Generic User Property Message Opcode

MESHX_MODEL_OP_GEN_BATTERY_GET

#define MESHX_MODEL_OP_GEN_BATTERY_GET   MESHX_MODEL_OP_2(0x82, 0x23)

MESHX_MODEL_OP_GEN_BATTERY_STATUS

#define MESHX_MODEL_OP_GEN_BATTERY_STATUS   MESHX_MODEL_OP_2(0x82, 0x24)

Generic Location Message Opcode

MESHX_MODEL_OP_GEN_CLIENT_PROPERTIES_GET

#define MESHX_MODEL_OP_GEN_CLIENT_PROPERTIES_GET   MESHX_MODEL_OP_1(0x4F)

MESHX_MODEL_OP_GEN_CLIENT_PROPERTIES_STATUS

#define MESHX_MODEL_OP_GEN_CLIENT_PROPERTIES_STATUS   MESHX_MODEL_OP_1(0x50)

Sensor Message Opcode

MESHX_MODEL_OP_GEN_DEF_TRANS_TIME_GET

#define MESHX_MODEL_OP_GEN_DEF_TRANS_TIME_GET   MESHX_MODEL_OP_2(0x82, 0x0D)

MESHX_MODEL_OP_GEN_DEF_TRANS_TIME_SET

#define MESHX_MODEL_OP_GEN_DEF_TRANS_TIME_SET   MESHX_MODEL_OP_2(0x82, 0x0E)

MESHX_MODEL_OP_GEN_DEF_TRANS_TIME_SET_UNACK

#define MESHX_MODEL_OP_GEN_DEF_TRANS_TIME_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x0F)

MESHX_MODEL_OP_GEN_DEF_TRANS_TIME_STATUS

#define MESHX_MODEL_OP_GEN_DEF_TRANS_TIME_STATUS   MESHX_MODEL_OP_2(0x82, 0x10)

Generic Power OnOff Message Opcode

MESHX_MODEL_OP_GEN_DELTA_SET

#define MESHX_MODEL_OP_GEN_DELTA_SET   MESHX_MODEL_OP_2(0x82, 0x09)

MESHX_MODEL_OP_GEN_DELTA_SET_UNACK

#define MESHX_MODEL_OP_GEN_DELTA_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x0A)

MESHX_MODEL_OP_GEN_LEVEL_GET

#define MESHX_MODEL_OP_GEN_LEVEL_GET   MESHX_MODEL_OP_2(0x82, 0x05)

MESHX_MODEL_OP_GEN_LEVEL_SET

#define MESHX_MODEL_OP_GEN_LEVEL_SET   MESHX_MODEL_OP_2(0x82, 0x06)

MESHX_MODEL_OP_GEN_LEVEL_SET_UNACK

#define MESHX_MODEL_OP_GEN_LEVEL_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x07)

MESHX_MODEL_OP_GEN_LEVEL_STATUS

#define MESHX_MODEL_OP_GEN_LEVEL_STATUS   MESHX_MODEL_OP_2(0x82, 0x08)

MESHX_MODEL_OP_GEN_LOC_GLOBAL_GET

#define MESHX_MODEL_OP_GEN_LOC_GLOBAL_GET   MESHX_MODEL_OP_2(0x82, 0x25)

MESHX_MODEL_OP_GEN_LOC_GLOBAL_SET

#define MESHX_MODEL_OP_GEN_LOC_GLOBAL_SET   MESHX_MODEL_OP_1(0x41)

MESHX_MODEL_OP_GEN_LOC_GLOBAL_SET_UNACK

#define MESHX_MODEL_OP_GEN_LOC_GLOBAL_SET_UNACK   MESHX_MODEL_OP_1(0x42)

MESHX_MODEL_OP_GEN_LOC_GLOBAL_STATUS

#define MESHX_MODEL_OP_GEN_LOC_GLOBAL_STATUS   MESHX_MODEL_OP_1(0x40)

MESHX_MODEL_OP_GEN_LOC_LOCAL_GET

#define MESHX_MODEL_OP_GEN_LOC_LOCAL_GET   MESHX_MODEL_OP_2(0x82, 0x26)

MESHX_MODEL_OP_GEN_LOC_LOCAL_SET

#define MESHX_MODEL_OP_GEN_LOC_LOCAL_SET   MESHX_MODEL_OP_2(0x82, 0x28)

MESHX_MODEL_OP_GEN_LOC_LOCAL_SET_UNACK

#define MESHX_MODEL_OP_GEN_LOC_LOCAL_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x29)

Generic Manufacturer Property Message Opcode

MESHX_MODEL_OP_GEN_LOC_LOCAL_STATUS

#define MESHX_MODEL_OP_GEN_LOC_LOCAL_STATUS   MESHX_MODEL_OP_2(0x82, 0x27)

Generic Location Setup Message Opcode

MESHX_MODEL_OP_GEN_MANUFACTURER_PROPERTIES_GET

#define MESHX_MODEL_OP_GEN_MANUFACTURER_PROPERTIES_GET   MESHX_MODEL_OP_2(0x82, 0x2A)

MESHX_MODEL_OP_GEN_MANUFACTURER_PROPERTIES_STATUS

#define MESHX_MODEL_OP_GEN_MANUFACTURER_PROPERTIES_STATUS   MESHX_MODEL_OP_1(0x43)

MESHX_MODEL_OP_GEN_MANUFACTURER_PROPERTY_GET

#define MESHX_MODEL_OP_GEN_MANUFACTURER_PROPERTY_GET   MESHX_MODEL_OP_2(0x82, 0x2B)

MESHX_MODEL_OP_GEN_MANUFACTURER_PROPERTY_SET

#define MESHX_MODEL_OP_GEN_MANUFACTURER_PROPERTY_SET   MESHX_MODEL_OP_1(0x44)

MESHX_MODEL_OP_GEN_MANUFACTURER_PROPERTY_SET_UNACK

#define MESHX_MODEL_OP_GEN_MANUFACTURER_PROPERTY_SET_UNACK   MESHX_MODEL_OP_1(0x45)

MESHX_MODEL_OP_GEN_MANUFACTURER_PROPERTY_STATUS

#define MESHX_MODEL_OP_GEN_MANUFACTURER_PROPERTY_STATUS   MESHX_MODEL_OP_1(0x46)

Generic Admin Property Message Opcode

MESHX_MODEL_OP_GEN_MOVE_SET

#define MESHX_MODEL_OP_GEN_MOVE_SET   MESHX_MODEL_OP_2(0x82, 0x0B)

MESHX_MODEL_OP_GEN_MOVE_SET_UNACK

#define MESHX_MODEL_OP_GEN_MOVE_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x0C)

Generic Default Transition Time Message Opcode

MESHX_MODEL_OP_GEN_ONOFF_GET

#define MESHX_MODEL_OP_GEN_ONOFF_GET   MESHX_MODEL_OP_2(0x82, 0x01)

MESHX_MODEL_OP_GEN_ONOFF_SET

#define MESHX_MODEL_OP_GEN_ONOFF_SET   MESHX_MODEL_OP_2(0x82, 0x02)

MESHX_MODEL_OP_GEN_ONOFF_SET_UNACK

#define MESHX_MODEL_OP_GEN_ONOFF_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x03)

MESHX_MODEL_OP_GEN_ONOFF_STATUS

#define MESHX_MODEL_OP_GEN_ONOFF_STATUS   MESHX_MODEL_OP_2(0x82, 0x04)

Generic Level Message Opcode

MESHX_MODEL_OP_GEN_ONPOWERUP_GET

#define MESHX_MODEL_OP_GEN_ONPOWERUP_GET   MESHX_MODEL_OP_2(0x82, 0x11)

MESHX_MODEL_OP_GEN_ONPOWERUP_SET

#define MESHX_MODEL_OP_GEN_ONPOWERUP_SET   MESHX_MODEL_OP_2(0x82, 0x13)

MESHX_MODEL_OP_GEN_ONPOWERUP_SET_UNACK

#define MESHX_MODEL_OP_GEN_ONPOWERUP_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x14)

Generic Power Level Message Opcode

MESHX_MODEL_OP_GEN_ONPOWERUP_STATUS

#define MESHX_MODEL_OP_GEN_ONPOWERUP_STATUS   MESHX_MODEL_OP_2(0x82, 0x12)

Generic Power OnOff Setup Message Opcode

MESHX_MODEL_OP_GEN_POWER_DEFAULT_GET

#define MESHX_MODEL_OP_GEN_POWER_DEFAULT_GET   MESHX_MODEL_OP_2(0x82, 0x1B)

MESHX_MODEL_OP_GEN_POWER_DEFAULT_SET

#define MESHX_MODEL_OP_GEN_POWER_DEFAULT_SET   MESHX_MODEL_OP_2(0x82, 0x1F)

MESHX_MODEL_OP_GEN_POWER_DEFAULT_SET_UNACK

#define MESHX_MODEL_OP_GEN_POWER_DEFAULT_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x20)

MESHX_MODEL_OP_GEN_POWER_DEFAULT_STATUS

#define MESHX_MODEL_OP_GEN_POWER_DEFAULT_STATUS   MESHX_MODEL_OP_2(0x82, 0x1C)

MESHX_MODEL_OP_GEN_POWER_LAST_GET

#define MESHX_MODEL_OP_GEN_POWER_LAST_GET   MESHX_MODEL_OP_2(0x82, 0x19)

MESHX_MODEL_OP_GEN_POWER_LAST_STATUS

#define MESHX_MODEL_OP_GEN_POWER_LAST_STATUS   MESHX_MODEL_OP_2(0x82, 0x1A)

MESHX_MODEL_OP_GEN_POWER_LEVEL_GET

#define MESHX_MODEL_OP_GEN_POWER_LEVEL_GET   MESHX_MODEL_OP_2(0x82, 0x15)

MESHX_MODEL_OP_GEN_POWER_LEVEL_SET

#define MESHX_MODEL_OP_GEN_POWER_LEVEL_SET   MESHX_MODEL_OP_2(0x82, 0x16)

MESHX_MODEL_OP_GEN_POWER_LEVEL_SET_UNACK

#define MESHX_MODEL_OP_GEN_POWER_LEVEL_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x17)

MESHX_MODEL_OP_GEN_POWER_LEVEL_STATUS

#define MESHX_MODEL_OP_GEN_POWER_LEVEL_STATUS   MESHX_MODEL_OP_2(0x82, 0x18)

MESHX_MODEL_OP_GEN_POWER_RANGE_GET

#define MESHX_MODEL_OP_GEN_POWER_RANGE_GET   MESHX_MODEL_OP_2(0x82, 0x1D)

MESHX_MODEL_OP_GEN_POWER_RANGE_SET

#define MESHX_MODEL_OP_GEN_POWER_RANGE_SET   MESHX_MODEL_OP_2(0x82, 0x21)

MESHX_MODEL_OP_GEN_POWER_RANGE_SET_UNACK

#define MESHX_MODEL_OP_GEN_POWER_RANGE_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x22)

Generic Battery Message Opcode

MESHX_MODEL_OP_GEN_POWER_RANGE_STATUS

#define MESHX_MODEL_OP_GEN_POWER_RANGE_STATUS   MESHX_MODEL_OP_2(0x82, 0x1E)

Generic Power Level Setup Message Opcode

MESHX_MODEL_OP_GEN_USER_PROPERTIES_GET

#define MESHX_MODEL_OP_GEN_USER_PROPERTIES_GET   MESHX_MODEL_OP_2(0x82, 0x2E)

MESHX_MODEL_OP_GEN_USER_PROPERTIES_STATUS

#define MESHX_MODEL_OP_GEN_USER_PROPERTIES_STATUS   MESHX_MODEL_OP_1(0x4B)

MESHX_MODEL_OP_GEN_USER_PROPERTY_GET

#define MESHX_MODEL_OP_GEN_USER_PROPERTY_GET   MESHX_MODEL_OP_2(0x82, 0x2F)

MESHX_MODEL_OP_GEN_USER_PROPERTY_SET

#define MESHX_MODEL_OP_GEN_USER_PROPERTY_SET   MESHX_MODEL_OP_1(0x4C)

MESHX_MODEL_OP_GEN_USER_PROPERTY_SET_UNACK

#define MESHX_MODEL_OP_GEN_USER_PROPERTY_SET_UNACK   MESHX_MODEL_OP_1(0x4D)

MESHX_MODEL_OP_GEN_USER_PROPERTY_STATUS

#define MESHX_MODEL_OP_GEN_USER_PROPERTY_STATUS   MESHX_MODEL_OP_1(0x4E)

Generic Client Property Message Opcode

MESHX_MODEL_OP_HEALTH_CURRENT_STATUS

#define MESHX_MODEL_OP_HEALTH_CURRENT_STATUS   MESHX_MODEL_OP_1(0x04)

MESHX_MODEL_OP_HEALTH_FAULT_CLEAR

#define MESHX_MODEL_OP_HEALTH_FAULT_CLEAR   MESHX_MODEL_OP_2(0x80, 0x2F)

Health Fault Clear

MESHX_MODEL_OP_HEALTH_FAULT_CLEAR_UNACK

#define MESHX_MODEL_OP_HEALTH_FAULT_CLEAR_UNACK   MESHX_MODEL_OP_2(0x80, 0x30)

Health Fault Clear Unacknowledged

MESHX_MODEL_OP_HEALTH_FAULT_GET

#define MESHX_MODEL_OP_HEALTH_FAULT_GET   MESHX_MODEL_OP_2(0x80, 0x31)

Health Fault Get

MESHX_MODEL_OP_HEALTH_FAULT_STATUS

#define MESHX_MODEL_OP_HEALTH_FAULT_STATUS   MESHX_MODEL_OP_1(0x05)

MESHX_MODEL_OP_HEALTH_FAULT_TEST

#define MESHX_MODEL_OP_HEALTH_FAULT_TEST   MESHX_MODEL_OP_2(0x80, 0x32)

Health Fault Test

MESHX_MODEL_OP_HEALTH_FAULT_TEST_UNACK

#define MESHX_MODEL_OP_HEALTH_FAULT_TEST_UNACK   MESHX_MODEL_OP_2(0x80, 0x33)

Health Fault Test Unacknowledged

MESHX_MODEL_OP_HEALTH_PERIOD_GET

#define MESHX_MODEL_OP_HEALTH_PERIOD_GET   MESHX_MODEL_OP_2(0x80, 0x34)

Health Period Get

MESHX_MODEL_OP_HEALTH_PERIOD_SET

#define MESHX_MODEL_OP_HEALTH_PERIOD_SET   MESHX_MODEL_OP_2(0x80, 0x35)

Health Period Set

MESHX_MODEL_OP_HEALTH_PERIOD_SET_UNACK

#define MESHX_MODEL_OP_HEALTH_PERIOD_SET_UNACK   MESHX_MODEL_OP_2(0x80, 0x36)

Health Period Set Unacknowledged

MESHX_MODEL_OP_HEALTH_PERIOD_STATUS

#define MESHX_MODEL_OP_HEALTH_PERIOD_STATUS   MESHX_MODEL_OP_2(0x80, 0x37)

MESHX_MODEL_OP_HEARTBEAT_PUB_GET

#define MESHX_MODEL_OP_HEARTBEAT_PUB_GET   MESHX_MODEL_OP_2(0x80, 0x38)

Config Heartbeat Publication Get

MESHX_MODEL_OP_HEARTBEAT_PUB_SET

#define MESHX_MODEL_OP_HEARTBEAT_PUB_SET   MESHX_MODEL_OP_2(0x80, 0x39)

Config Heartbeat Publication Set

MESHX_MODEL_OP_HEARTBEAT_PUB_STATUS

#define MESHX_MODEL_OP_HEARTBEAT_PUB_STATUS   MESHX_MODEL_OP_1(0x06)

MESHX_MODEL_OP_HEARTBEAT_SUB_GET

#define MESHX_MODEL_OP_HEARTBEAT_SUB_GET   MESHX_MODEL_OP_2(0x80, 0x3a)

Config Heartbeat Subscription Get

MESHX_MODEL_OP_HEARTBEAT_SUB_SET

#define MESHX_MODEL_OP_HEARTBEAT_SUB_SET   MESHX_MODEL_OP_2(0x80, 0x3B)

Config Heartbeat Subscription Set

MESHX_MODEL_OP_HEARTBEAT_SUB_STATUS

#define MESHX_MODEL_OP_HEARTBEAT_SUB_STATUS   MESHX_MODEL_OP_2(0x80, 0x3C)

MESHX_MODEL_OP_KEY_REFRESH_PHASE_GET

#define MESHX_MODEL_OP_KEY_REFRESH_PHASE_GET   MESHX_MODEL_OP_2(0x80, 0x15)

Config Key Refresh Phase Get

MESHX_MODEL_OP_KEY_REFRESH_PHASE_SET

#define MESHX_MODEL_OP_KEY_REFRESH_PHASE_SET   MESHX_MODEL_OP_2(0x80, 0x16)

Config Key Refresh Phase Set

MESHX_MODEL_OP_KEY_REFRESH_PHASE_STATUS

#define MESHX_MODEL_OP_KEY_REFRESH_PHASE_STATUS   MESHX_MODEL_OP_2(0x80, 0x17)

MESHX_MODEL_OP_LIGHT_CTL_DEFAULT_GET

#define MESHX_MODEL_OP_LIGHT_CTL_DEFAULT_GET   MESHX_MODEL_OP_2(0x82, 0x67)

MESHX_MODEL_OP_LIGHT_CTL_DEFAULT_SET

#define MESHX_MODEL_OP_LIGHT_CTL_DEFAULT_SET   MESHX_MODEL_OP_2(0x82, 0x69)

MESHX_MODEL_OP_LIGHT_CTL_DEFAULT_SET_UNACK

#define MESHX_MODEL_OP_LIGHT_CTL_DEFAULT_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x6A)

MESHX_MODEL_OP_LIGHT_CTL_DEFAULT_STATUS

#define MESHX_MODEL_OP_LIGHT_CTL_DEFAULT_STATUS   MESHX_MODEL_OP_2(0x82, 0x68)

Light CTL Setup Message Opcode

MESHX_MODEL_OP_LIGHT_CTL_GET

#define MESHX_MODEL_OP_LIGHT_CTL_GET   MESHX_MODEL_OP_2(0x82, 0x5D)

MESHX_MODEL_OP_LIGHT_CTL_SET

#define MESHX_MODEL_OP_LIGHT_CTL_SET   MESHX_MODEL_OP_2(0x82, 0x5E)

MESHX_MODEL_OP_LIGHT_CTL_SET_UNACK

#define MESHX_MODEL_OP_LIGHT_CTL_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x5F)

MESHX_MODEL_OP_LIGHT_CTL_STATUS

#define MESHX_MODEL_OP_LIGHT_CTL_STATUS   MESHX_MODEL_OP_2(0x82, 0x60)

MESHX_MODEL_OP_LIGHT_CTL_TEMPERATURE_GET

#define MESHX_MODEL_OP_LIGHT_CTL_TEMPERATURE_GET   MESHX_MODEL_OP_2(0x82, 0x61)

MESHX_MODEL_OP_LIGHT_CTL_TEMPERATURE_RANGE_GET

#define MESHX_MODEL_OP_LIGHT_CTL_TEMPERATURE_RANGE_GET   MESHX_MODEL_OP_2(0x82, 0x62)

MESHX_MODEL_OP_LIGHT_CTL_TEMPERATURE_RANGE_SET

#define MESHX_MODEL_OP_LIGHT_CTL_TEMPERATURE_RANGE_SET   MESHX_MODEL_OP_2(0x82, 0x6B)

MESHX_MODEL_OP_LIGHT_CTL_TEMPERATURE_RANGE_SET_UNACK

#define MESHX_MODEL_OP_LIGHT_CTL_TEMPERATURE_RANGE_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x6C)

Light HSL Message Opcode

MESHX_MODEL_OP_LIGHT_CTL_TEMPERATURE_RANGE_STATUS

#define MESHX_MODEL_OP_LIGHT_CTL_TEMPERATURE_RANGE_STATUS   MESHX_MODEL_OP_2(0x82, 0x63)

MESHX_MODEL_OP_LIGHT_CTL_TEMPERATURE_SET

#define MESHX_MODEL_OP_LIGHT_CTL_TEMPERATURE_SET   MESHX_MODEL_OP_2(0x82, 0x64)

MESHX_MODEL_OP_LIGHT_CTL_TEMPERATURE_SET_UNACK

#define MESHX_MODEL_OP_LIGHT_CTL_TEMPERATURE_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x65)

MESHX_MODEL_OP_LIGHT_CTL_TEMPERATURE_STATUS

#define MESHX_MODEL_OP_LIGHT_CTL_TEMPERATURE_STATUS   MESHX_MODEL_OP_2(0x82, 0x66)

MESHX_MODEL_OP_LIGHT_HSL_DEFAULT_GET

#define MESHX_MODEL_OP_LIGHT_HSL_DEFAULT_GET   MESHX_MODEL_OP_2(0x82, 0x7B)

MESHX_MODEL_OP_LIGHT_HSL_DEFAULT_SET

#define MESHX_MODEL_OP_LIGHT_HSL_DEFAULT_SET   MESHX_MODEL_OP_2(0x82, 0x7F)

MESHX_MODEL_OP_LIGHT_HSL_DEFAULT_SET_UNACK

#define MESHX_MODEL_OP_LIGHT_HSL_DEFAULT_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x80)

MESHX_MODEL_OP_LIGHT_HSL_DEFAULT_STATUS

#define MESHX_MODEL_OP_LIGHT_HSL_DEFAULT_STATUS   MESHX_MODEL_OP_2(0x82, 0x7C)

MESHX_MODEL_OP_LIGHT_HSL_GET

#define MESHX_MODEL_OP_LIGHT_HSL_GET   MESHX_MODEL_OP_2(0x82, 0x6D)

MESHX_MODEL_OP_LIGHT_HSL_HUE_GET

#define MESHX_MODEL_OP_LIGHT_HSL_HUE_GET   MESHX_MODEL_OP_2(0x82, 0x6E)

MESHX_MODEL_OP_LIGHT_HSL_HUE_SET

#define MESHX_MODEL_OP_LIGHT_HSL_HUE_SET   MESHX_MODEL_OP_2(0x82, 0x6F)

MESHX_MODEL_OP_LIGHT_HSL_HUE_SET_UNACK

#define MESHX_MODEL_OP_LIGHT_HSL_HUE_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x70)

MESHX_MODEL_OP_LIGHT_HSL_HUE_STATUS

#define MESHX_MODEL_OP_LIGHT_HSL_HUE_STATUS   MESHX_MODEL_OP_2(0x82, 0x71)

MESHX_MODEL_OP_LIGHT_HSL_RANGE_GET

#define MESHX_MODEL_OP_LIGHT_HSL_RANGE_GET   MESHX_MODEL_OP_2(0x82, 0x7D)

MESHX_MODEL_OP_LIGHT_HSL_RANGE_SET

#define MESHX_MODEL_OP_LIGHT_HSL_RANGE_SET   MESHX_MODEL_OP_2(0x82, 0x81)

MESHX_MODEL_OP_LIGHT_HSL_RANGE_SET_UNACK

#define MESHX_MODEL_OP_LIGHT_HSL_RANGE_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x82)

Light xyL Message Opcode

MESHX_MODEL_OP_LIGHT_HSL_RANGE_STATUS

#define MESHX_MODEL_OP_LIGHT_HSL_RANGE_STATUS   MESHX_MODEL_OP_2(0x82, 0x7E)

Light HSL Setup Message Opcode

MESHX_MODEL_OP_LIGHT_HSL_SATURATION_GET

#define MESHX_MODEL_OP_LIGHT_HSL_SATURATION_GET   MESHX_MODEL_OP_2(0x82, 0x72)

MESHX_MODEL_OP_LIGHT_HSL_SATURATION_SET

#define MESHX_MODEL_OP_LIGHT_HSL_SATURATION_SET   MESHX_MODEL_OP_2(0x82, 0x73)

MESHX_MODEL_OP_LIGHT_HSL_SATURATION_SET_UNACK

#define MESHX_MODEL_OP_LIGHT_HSL_SATURATION_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x74)

MESHX_MODEL_OP_LIGHT_HSL_SATURATION_STATUS

#define MESHX_MODEL_OP_LIGHT_HSL_SATURATION_STATUS   MESHX_MODEL_OP_2(0x82, 0x75)

MESHX_MODEL_OP_LIGHT_HSL_SET

#define MESHX_MODEL_OP_LIGHT_HSL_SET   MESHX_MODEL_OP_2(0x82, 0x76)

MESHX_MODEL_OP_LIGHT_HSL_SET_UNACK

#define MESHX_MODEL_OP_LIGHT_HSL_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x77)

MESHX_MODEL_OP_LIGHT_HSL_STATUS

#define MESHX_MODEL_OP_LIGHT_HSL_STATUS   MESHX_MODEL_OP_2(0x82, 0x78)

MESHX_MODEL_OP_LIGHT_HSL_TARGET_GET

#define MESHX_MODEL_OP_LIGHT_HSL_TARGET_GET   MESHX_MODEL_OP_2(0x82, 0x79)

MESHX_MODEL_OP_LIGHT_HSL_TARGET_STATUS

#define MESHX_MODEL_OP_LIGHT_HSL_TARGET_STATUS   MESHX_MODEL_OP_2(0x82, 0x7A)

MESHX_MODEL_OP_LIGHT_LC_LIGHT_ONOFF_GET

#define MESHX_MODEL_OP_LIGHT_LC_LIGHT_ONOFF_GET   MESHX_MODEL_OP_2(0x82, 0x99)

MESHX_MODEL_OP_LIGHT_LC_LIGHT_ONOFF_SET

#define MESHX_MODEL_OP_LIGHT_LC_LIGHT_ONOFF_SET   MESHX_MODEL_OP_2(0x82, 0x9A)

MESHX_MODEL_OP_LIGHT_LC_LIGHT_ONOFF_SET_UNACK

#define MESHX_MODEL_OP_LIGHT_LC_LIGHT_ONOFF_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x9B)

MESHX_MODEL_OP_LIGHT_LC_LIGHT_ONOFF_STATUS

#define MESHX_MODEL_OP_LIGHT_LC_LIGHT_ONOFF_STATUS   MESHX_MODEL_OP_2(0x82, 0x9C)

MESHX_MODEL_OP_LIGHT_LC_MODE_GET

#define MESHX_MODEL_OP_LIGHT_LC_MODE_GET   MESHX_MODEL_OP_2(0x82, 0x91)

MESHX_MODEL_OP_LIGHT_LC_MODE_SET

#define MESHX_MODEL_OP_LIGHT_LC_MODE_SET   MESHX_MODEL_OP_2(0x82, 0x92)

MESHX_MODEL_OP_LIGHT_LC_MODE_SET_UNACK

#define MESHX_MODEL_OP_LIGHT_LC_MODE_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x93)

MESHX_MODEL_OP_LIGHT_LC_MODE_STATUS

#define MESHX_MODEL_OP_LIGHT_LC_MODE_STATUS   MESHX_MODEL_OP_2(0x82, 0x94)

MESHX_MODEL_OP_LIGHT_LC_OM_GET

#define MESHX_MODEL_OP_LIGHT_LC_OM_GET   MESHX_MODEL_OP_2(0x82, 0x95)

MESHX_MODEL_OP_LIGHT_LC_OM_SET

#define MESHX_MODEL_OP_LIGHT_LC_OM_SET   MESHX_MODEL_OP_2(0x82, 0x96)

MESHX_MODEL_OP_LIGHT_LC_OM_SET_UNACK

#define MESHX_MODEL_OP_LIGHT_LC_OM_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x97)

MESHX_MODEL_OP_LIGHT_LC_OM_STATUS

#define MESHX_MODEL_OP_LIGHT_LC_OM_STATUS   MESHX_MODEL_OP_2(0x82, 0x98)

MESHX_MODEL_OP_LIGHT_LC_PROPERTY_GET

#define MESHX_MODEL_OP_LIGHT_LC_PROPERTY_GET   MESHX_MODEL_OP_2(0x82, 0x9D)

MESHX_MODEL_OP_LIGHT_LC_PROPERTY_SET

#define MESHX_MODEL_OP_LIGHT_LC_PROPERTY_SET   MESHX_MODEL_OP_1(0x62)

MESHX_MODEL_OP_LIGHT_LC_PROPERTY_SET_UNACK

#define MESHX_MODEL_OP_LIGHT_LC_PROPERTY_SET_UNACK   MESHX_MODEL_OP_1(0x63)

MESHX_MODEL_OP_LIGHT_LC_PROPERTY_STATUS

#define MESHX_MODEL_OP_LIGHT_LC_PROPERTY_STATUS   MESHX_MODEL_OP_1(0x64)

MESHX_MODEL_OP_LIGHT_LIGHTNESS_DEFAULT_GET

#define MESHX_MODEL_OP_LIGHT_LIGHTNESS_DEFAULT_GET   MESHX_MODEL_OP_2(0x82, 0x55)

MESHX_MODEL_OP_LIGHT_LIGHTNESS_DEFAULT_SET

#define MESHX_MODEL_OP_LIGHT_LIGHTNESS_DEFAULT_SET   MESHX_MODEL_OP_2(0x82, 0x59)

MESHX_MODEL_OP_LIGHT_LIGHTNESS_DEFAULT_SET_UNACK

#define MESHX_MODEL_OP_LIGHT_LIGHTNESS_DEFAULT_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x5A)

MESHX_MODEL_OP_LIGHT_LIGHTNESS_DEFAULT_STATUS

#define MESHX_MODEL_OP_LIGHT_LIGHTNESS_DEFAULT_STATUS   MESHX_MODEL_OP_2(0x82, 0x56)

MESHX_MODEL_OP_LIGHT_LIGHTNESS_GET

#define MESHX_MODEL_OP_LIGHT_LIGHTNESS_GET   MESHX_MODEL_OP_2(0x82, 0x4B)

MESHX_MODEL_OP_LIGHT_LIGHTNESS_LAST_GET

#define MESHX_MODEL_OP_LIGHT_LIGHTNESS_LAST_GET   MESHX_MODEL_OP_2(0x82, 0x53)

MESHX_MODEL_OP_LIGHT_LIGHTNESS_LAST_STATUS

#define MESHX_MODEL_OP_LIGHT_LIGHTNESS_LAST_STATUS   MESHX_MODEL_OP_2(0x82, 0x54)

MESHX_MODEL_OP_LIGHT_LIGHTNESS_LINEAR_GET

#define MESHX_MODEL_OP_LIGHT_LIGHTNESS_LINEAR_GET   MESHX_MODEL_OP_2(0x82, 0x4F)

MESHX_MODEL_OP_LIGHT_LIGHTNESS_LINEAR_SET

#define MESHX_MODEL_OP_LIGHT_LIGHTNESS_LINEAR_SET   MESHX_MODEL_OP_2(0x82, 0x50)

MESHX_MODEL_OP_LIGHT_LIGHTNESS_LINEAR_SET_UNACK

#define MESHX_MODEL_OP_LIGHT_LIGHTNESS_LINEAR_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x51)

MESHX_MODEL_OP_LIGHT_LIGHTNESS_LINEAR_STATUS

#define MESHX_MODEL_OP_LIGHT_LIGHTNESS_LINEAR_STATUS   MESHX_MODEL_OP_2(0x82, 0x52)

MESHX_MODEL_OP_LIGHT_LIGHTNESS_RANGE_GET

#define MESHX_MODEL_OP_LIGHT_LIGHTNESS_RANGE_GET   MESHX_MODEL_OP_2(0x82, 0x57)

MESHX_MODEL_OP_LIGHT_LIGHTNESS_RANGE_SET

#define MESHX_MODEL_OP_LIGHT_LIGHTNESS_RANGE_SET   MESHX_MODEL_OP_2(0x82, 0x5B)

MESHX_MODEL_OP_LIGHT_LIGHTNESS_RANGE_SET_UNACK

#define MESHX_MODEL_OP_LIGHT_LIGHTNESS_RANGE_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x5C)

Light CTL Message Opcode

MESHX_MODEL_OP_LIGHT_LIGHTNESS_RANGE_STATUS

#define MESHX_MODEL_OP_LIGHT_LIGHTNESS_RANGE_STATUS   MESHX_MODEL_OP_2(0x82, 0x58)

Light Lightness Setup Message Opcode

MESHX_MODEL_OP_LIGHT_LIGHTNESS_SET

#define MESHX_MODEL_OP_LIGHT_LIGHTNESS_SET   MESHX_MODEL_OP_2(0x82, 0x4C)

MESHX_MODEL_OP_LIGHT_LIGHTNESS_SET_UNACK

#define MESHX_MODEL_OP_LIGHT_LIGHTNESS_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x4D)

MESHX_MODEL_OP_LIGHT_LIGHTNESS_STATUS

#define MESHX_MODEL_OP_LIGHT_LIGHTNESS_STATUS   MESHX_MODEL_OP_2(0x82, 0x4E)

MESHX_MODEL_OP_LIGHT_XYL_DEFAULT_GET

#define MESHX_MODEL_OP_LIGHT_XYL_DEFAULT_GET   MESHX_MODEL_OP_2(0x82, 0x89)

MESHX_MODEL_OP_LIGHT_XYL_DEFAULT_SET

#define MESHX_MODEL_OP_LIGHT_XYL_DEFAULT_SET   MESHX_MODEL_OP_2(0x82, 0x8D)

MESHX_MODEL_OP_LIGHT_XYL_DEFAULT_SET_UNACK

#define MESHX_MODEL_OP_LIGHT_XYL_DEFAULT_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x8E)

MESHX_MODEL_OP_LIGHT_XYL_DEFAULT_STATUS

#define MESHX_MODEL_OP_LIGHT_XYL_DEFAULT_STATUS   MESHX_MODEL_OP_2(0x82, 0x8A)

MESHX_MODEL_OP_LIGHT_XYL_GET

#define MESHX_MODEL_OP_LIGHT_XYL_GET   MESHX_MODEL_OP_2(0x82, 0x83)

MESHX_MODEL_OP_LIGHT_XYL_RANGE_GET

#define MESHX_MODEL_OP_LIGHT_XYL_RANGE_GET   MESHX_MODEL_OP_2(0x82, 0x8B)

MESHX_MODEL_OP_LIGHT_XYL_RANGE_SET

#define MESHX_MODEL_OP_LIGHT_XYL_RANGE_SET   MESHX_MODEL_OP_2(0x82, 0x8F)

MESHX_MODEL_OP_LIGHT_XYL_RANGE_SET_UNACK

#define MESHX_MODEL_OP_LIGHT_XYL_RANGE_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x90)

Light Control Message Opcode

MESHX_MODEL_OP_LIGHT_XYL_RANGE_STATUS

#define MESHX_MODEL_OP_LIGHT_XYL_RANGE_STATUS   MESHX_MODEL_OP_2(0x82, 0x8C)

Light xyL Setup Message Opcode

MESHX_MODEL_OP_LIGHT_XYL_SET

#define MESHX_MODEL_OP_LIGHT_XYL_SET   MESHX_MODEL_OP_2(0x82, 0x84)

MESHX_MODEL_OP_LIGHT_XYL_SET_UNACK

#define MESHX_MODEL_OP_LIGHT_XYL_SET_UNACK   MESHX_MODEL_OP_2(0x82, 0x85)

MESHX_MODEL_OP_LIGHT_XYL_STATUS

#define MESHX_MODEL_OP_LIGHT_XYL_STATUS   MESHX_MODEL_OP_2(0x82, 0x86)

MESHX_MODEL_OP_LIGHT_XYL_TARGET_GET

#define MESHX_MODEL_OP_LIGHT_XYL_TARGET_GET   MESHX_MODEL_OP_2(0x82, 0x87)

MESHX_MODEL_OP_LIGHT_XYL_TARGET_STATUS

#define MESHX_MODEL_OP_LIGHT_XYL_TARGET_STATUS   MESHX_MODEL_OP_2(0x82, 0x88)

MESHX_MODEL_OP_LPN_POLLTIMEOUT_GET

#define MESHX_MODEL_OP_LPN_POLLTIMEOUT_GET   MESHX_MODEL_OP_2(0x80, 0x2D)

Config Low Power Node PollTimeout Get

MESHX_MODEL_OP_LPN_POLLTIMEOUT_STATUS

#define MESHX_MODEL_OP_LPN_POLLTIMEOUT_STATUS   MESHX_MODEL_OP_2(0x80, 0x2E)

MESHX_MODEL_OP_MODEL_APP_BIND

#define MESHX_MODEL_OP_MODEL_APP_BIND   MESHX_MODEL_OP_2(0x80, 0x3D)

Config Model App Bind

MESHX_MODEL_OP_MODEL_APP_STATUS

#define MESHX_MODEL_OP_MODEL_APP_STATUS   MESHX_MODEL_OP_2(0x80, 0x3E)

MESHX_MODEL_OP_MODEL_APP_UNBIND

#define MESHX_MODEL_OP_MODEL_APP_UNBIND   MESHX_MODEL_OP_2(0x80, 0x3F)

Config Model App Unbind

MESHX_MODEL_OP_MODEL_PUB_GET

#define MESHX_MODEL_OP_MODEL_PUB_GET   MESHX_MODEL_OP_2(0x80, 0x18)

Config Model Publication Get

MESHX_MODEL_OP_MODEL_PUB_SET

#define MESHX_MODEL_OP_MODEL_PUB_SET   MESHX_MODEL_OP_1(0x03)

Config Model Publication Set

MESHX_MODEL_OP_MODEL_PUB_STATUS

#define MESHX_MODEL_OP_MODEL_PUB_STATUS   MESHX_MODEL_OP_2(0x80, 0x19)

MESHX_MODEL_OP_MODEL_PUB_VIRTUAL_ADDR_SET

#define MESHX_MODEL_OP_MODEL_PUB_VIRTUAL_ADDR_SET   MESHX_MODEL_OP_2(0x80, 0x1A)

Config Model Publication Virtual Address Set

MESHX_MODEL_OP_MODEL_SUB_ADD

#define MESHX_MODEL_OP_MODEL_SUB_ADD   MESHX_MODEL_OP_2(0x80, 0x1B)

Config Model Subscription Add

MESHX_MODEL_OP_MODEL_SUB_DELETE

#define MESHX_MODEL_OP_MODEL_SUB_DELETE   MESHX_MODEL_OP_2(0x80, 0x1C)

Config Model Subscription Delete

MESHX_MODEL_OP_MODEL_SUB_DELETE_ALL

#define MESHX_MODEL_OP_MODEL_SUB_DELETE_ALL   MESHX_MODEL_OP_2(0x80, 0x1D)

Config Model Subscription Delete All

MESHX_MODEL_OP_MODEL_SUB_OVERWRITE

#define MESHX_MODEL_OP_MODEL_SUB_OVERWRITE   MESHX_MODEL_OP_2(0x80, 0x1E)

Config Model Subscription Overwrite

MESHX_MODEL_OP_MODEL_SUB_STATUS

#define MESHX_MODEL_OP_MODEL_SUB_STATUS   MESHX_MODEL_OP_2(0x80, 0x1F)

MESHX_MODEL_OP_MODEL_SUB_VIRTUAL_ADDR_ADD

#define MESHX_MODEL_OP_MODEL_SUB_VIRTUAL_ADDR_ADD   MESHX_MODEL_OP_2(0x80, 0x20)

Config Model Subscription Virtual Address Add

MESHX_MODEL_OP_MODEL_SUB_VIRTUAL_ADDR_DELETE

#define MESHX_MODEL_OP_MODEL_SUB_VIRTUAL_ADDR_DELETE   MESHX_MODEL_OP_2(0x80, 0x21)

Config Model Subscription Virtual Address Delete

MESHX_MODEL_OP_MODEL_SUB_VIRTUAL_ADDR_OVERWRITE

#define MESHX_MODEL_OP_MODEL_SUB_VIRTUAL_ADDR_OVERWRITE   MESHX_MODEL_OP_2(0x80, 0x22)

Config Model Subscription Virtual Address Overwrite

MESHX_MODEL_OP_NET_KEY_ADD

#define MESHX_MODEL_OP_NET_KEY_ADD   MESHX_MODEL_OP_2(0x80, 0x40)

Config NetKey Add

MESHX_MODEL_OP_NET_KEY_DELETE

#define MESHX_MODEL_OP_NET_KEY_DELETE   MESHX_MODEL_OP_2(0x80, 0x41)

Config NetKey Delete

MESHX_MODEL_OP_NET_KEY_GET

#define MESHX_MODEL_OP_NET_KEY_GET   MESHX_MODEL_OP_2(0x80, 0x42)

Config NetKey Get

MESHX_MODEL_OP_NET_KEY_LIST

#define MESHX_MODEL_OP_NET_KEY_LIST   MESHX_MODEL_OP_2(0x80, 0x43)

MESHX_MODEL_OP_NET_KEY_STATUS

#define MESHX_MODEL_OP_NET_KEY_STATUS   MESHX_MODEL_OP_2(0x80, 0x44)

MESHX_MODEL_OP_NET_KEY_UPDATE

#define MESHX_MODEL_OP_NET_KEY_UPDATE   MESHX_MODEL_OP_2(0x80, 0x45)

Config NetKey Update

MESHX_MODEL_OP_NETWORK_TRANSMIT_GET

#define MESHX_MODEL_OP_NETWORK_TRANSMIT_GET   MESHX_MODEL_OP_2(0x80, 0x23)

Config Network Transmit Get

MESHX_MODEL_OP_NETWORK_TRANSMIT_SET

#define MESHX_MODEL_OP_NETWORK_TRANSMIT_SET   MESHX_MODEL_OP_2(0x80, 0x24)

Config Network Transmit Set

MESHX_MODEL_OP_NETWORK_TRANSMIT_STATUS

#define MESHX_MODEL_OP_NETWORK_TRANSMIT_STATUS   MESHX_MODEL_OP_2(0x80, 0x25)

MESHX_MODEL_OP_NODE_IDENTITY_GET

#define MESHX_MODEL_OP_NODE_IDENTITY_GET   MESHX_MODEL_OP_2(0x80, 0x46)

Config Node Identity Get

MESHX_MODEL_OP_NODE_IDENTITY_SET

#define MESHX_MODEL_OP_NODE_IDENTITY_SET   MESHX_MODEL_OP_2(0x80, 0x47)

Config Node Identity Set

MESHX_MODEL_OP_NODE_IDENTITY_STATUS

#define MESHX_MODEL_OP_NODE_IDENTITY_STATUS   MESHX_MODEL_OP_2(0x80, 0x48)

MESHX_MODEL_OP_NODE_RESET

#define MESHX_MODEL_OP_NODE_RESET   MESHX_MODEL_OP_2(0x80, 0x49)

Config Node Reset

MESHX_MODEL_OP_NODE_RESET_STATUS

#define MESHX_MODEL_OP_NODE_RESET_STATUS   MESHX_MODEL_OP_2(0x80, 0x4A)

MESHX_MODEL_OP_RELAY_GET

#define MESHX_MODEL_OP_RELAY_GET   MESHX_MODEL_OP_2(0x80, 0x26)

Config Relay Get

MESHX_MODEL_OP_RELAY_SET

#define MESHX_MODEL_OP_RELAY_SET   MESHX_MODEL_OP_2(0x80, 0x27)

Config Relay Set

MESHX_MODEL_OP_RELAY_STATUS

#define MESHX_MODEL_OP_RELAY_STATUS   MESHX_MODEL_OP_2(0x80, 0x28)

MESHX_MODEL_OP_SCENE_DELETE

#define MESHX_MODEL_OP_SCENE_DELETE   MESHX_MODEL_OP_2(0x82, 0x9E)

MESHX_MODEL_OP_SCENE_DELETE_UNACK

#define MESHX_MODEL_OP_SCENE_DELETE_UNACK   MESHX_MODEL_OP_2(0x82, 0x9F)

Scheduler Message Opcode

MESHX_MODEL_OP_SCENE_GET

#define MESHX_MODEL_OP_SCENE_GET   MESHX_MODEL_OP_2(0x82, 0x41)

MESHX_MODEL_OP_SCENE_RECALL

#define MESHX_MODEL_OP_SCENE_RECALL   MESHX_MODEL_OP_2(0x82, 0x42)

MESHX_MODEL_OP_SCENE_RECALL_UNACK

#define MESHX_MODEL_OP_SCENE_RECALL_UNACK   MESHX_MODEL_OP_2(0x82, 0x43)

MESHX_MODEL_OP_SCENE_REGISTER_GET

#define MESHX_MODEL_OP_SCENE_REGISTER_GET   MESHX_MODEL_OP_2(0x82, 0x44)

MESHX_MODEL_OP_SCENE_REGISTER_STATUS

#define MESHX_MODEL_OP_SCENE_REGISTER_STATUS   MESHX_MODEL_OP_2(0x82, 0x45)

Scene Setup Message Opcode

MESHX_MODEL_OP_SCENE_STATUS

#define MESHX_MODEL_OP_SCENE_STATUS   MESHX_MODEL_OP_1(0x5E)

MESHX_MODEL_OP_SCENE_STORE

#define MESHX_MODEL_OP_SCENE_STORE   MESHX_MODEL_OP_2(0x82, 0x46)

MESHX_MODEL_OP_SCENE_STORE_UNACK

#define MESHX_MODEL_OP_SCENE_STORE_UNACK   MESHX_MODEL_OP_2(0x82, 0x47)

MESHX_MODEL_OP_SCHEDULER_ACT_GET

#define MESHX_MODEL_OP_SCHEDULER_ACT_GET   MESHX_MODEL_OP_2(0x82, 0x48)

MESHX_MODEL_OP_SCHEDULER_ACT_SET

#define MESHX_MODEL_OP_SCHEDULER_ACT_SET   MESHX_MODEL_OP_1(0x60)

MESHX_MODEL_OP_SCHEDULER_ACT_SET_UNACK

#define MESHX_MODEL_OP_SCHEDULER_ACT_SET_UNACK   MESHX_MODEL_OP_1(0x61)

Light Lightness Message Opcode

MESHX_MODEL_OP_SCHEDULER_ACT_STATUS

#define MESHX_MODEL_OP_SCHEDULER_ACT_STATUS   MESHX_MODEL_OP_1(0x5F)

MESHX_MODEL_OP_SCHEDULER_GET

#define MESHX_MODEL_OP_SCHEDULER_GET   MESHX_MODEL_OP_2(0x82, 0x49)

MESHX_MODEL_OP_SCHEDULER_STATUS

#define MESHX_MODEL_OP_SCHEDULER_STATUS   MESHX_MODEL_OP_2(0x82, 0x4A)

Scheduler Setup Message Opcode

MESHX_MODEL_OP_SENSOR_CADENCE_GET

#define MESHX_MODEL_OP_SENSOR_CADENCE_GET   MESHX_MODEL_OP_2(0x82, 0x34)

MESHX_MODEL_OP_SENSOR_CADENCE_SET

#define MESHX_MODEL_OP_SENSOR_CADENCE_SET   MESHX_MODEL_OP_1(0x55)

MESHX_MODEL_OP_SENSOR_CADENCE_SET_UNACK

#define MESHX_MODEL_OP_SENSOR_CADENCE_SET_UNACK   MESHX_MODEL_OP_1(0x56)

MESHX_MODEL_OP_SENSOR_CADENCE_STATUS

#define MESHX_MODEL_OP_SENSOR_CADENCE_STATUS   MESHX_MODEL_OP_1(0x57)

MESHX_MODEL_OP_SENSOR_COLUMN_GET

#define MESHX_MODEL_OP_SENSOR_COLUMN_GET   MESHX_MODEL_OP_2(0x82, 0x32)

MESHX_MODEL_OP_SENSOR_COLUMN_STATUS

#define MESHX_MODEL_OP_SENSOR_COLUMN_STATUS   MESHX_MODEL_OP_1(0x53)

MESHX_MODEL_OP_SENSOR_DESCRIPTOR_GET

#define MESHX_MODEL_OP_SENSOR_DESCRIPTOR_GET   MESHX_MODEL_OP_2(0x82, 0x30)

MESHX_MODEL_OP_SENSOR_DESCRIPTOR_STATUS

#define MESHX_MODEL_OP_SENSOR_DESCRIPTOR_STATUS   MESHX_MODEL_OP_1(0x51)

MESHX_MODEL_OP_SENSOR_GET

#define MESHX_MODEL_OP_SENSOR_GET   MESHX_MODEL_OP_2(0x82, 0x31)

MESHX_MODEL_OP_SENSOR_SERIES_GET

#define MESHX_MODEL_OP_SENSOR_SERIES_GET   MESHX_MODEL_OP_2(0x82, 0x33)

MESHX_MODEL_OP_SENSOR_SERIES_STATUS

#define MESHX_MODEL_OP_SENSOR_SERIES_STATUS   MESHX_MODEL_OP_1(0x54)

Sensor Setup Message Opcode

MESHX_MODEL_OP_SENSOR_SETTING_GET

#define MESHX_MODEL_OP_SENSOR_SETTING_GET   MESHX_MODEL_OP_2(0x82, 0x36)

MESHX_MODEL_OP_SENSOR_SETTING_SET

#define MESHX_MODEL_OP_SENSOR_SETTING_SET   MESHX_MODEL_OP_1(0x59)

MESHX_MODEL_OP_SENSOR_SETTING_SET_UNACK

#define MESHX_MODEL_OP_SENSOR_SETTING_SET_UNACK   MESHX_MODEL_OP_1(0x5A)

MESHX_MODEL_OP_SENSOR_SETTING_STATUS

#define MESHX_MODEL_OP_SENSOR_SETTING_STATUS   MESHX_MODEL_OP_1(0x5B)

Time Message Opcode

MESHX_MODEL_OP_SENSOR_SETTINGS_GET

#define MESHX_MODEL_OP_SENSOR_SETTINGS_GET   MESHX_MODEL_OP_2(0x82, 0x35)

MESHX_MODEL_OP_SENSOR_SETTINGS_STATUS

#define MESHX_MODEL_OP_SENSOR_SETTINGS_STATUS   MESHX_MODEL_OP_1(0x58)

MESHX_MODEL_OP_SENSOR_STATUS

#define MESHX_MODEL_OP_SENSOR_STATUS   MESHX_MODEL_OP_1(0x52)

MESHX_MODEL_OP_SIG_MODEL_APP_GET

#define MESHX_MODEL_OP_SIG_MODEL_APP_GET   MESHX_MODEL_OP_2(0x80, 0x4B)

Config SIG Model App Get

MESHX_MODEL_OP_SIG_MODEL_APP_LIST

#define MESHX_MODEL_OP_SIG_MODEL_APP_LIST   MESHX_MODEL_OP_2(0x80, 0x4C)

MESHX_MODEL_OP_SIG_MODEL_SUB_GET

#define MESHX_MODEL_OP_SIG_MODEL_SUB_GET   MESHX_MODEL_OP_2(0x80, 0x29)

Config SIG Model Subscription Get

MESHX_MODEL_OP_SIG_MODEL_SUB_LIST

#define MESHX_MODEL_OP_SIG_MODEL_SUB_LIST   MESHX_MODEL_OP_2(0x80, 0x2A)

MESHX_MODEL_OP_TAI_UTC_DELTA_GET

#define MESHX_MODEL_OP_TAI_UTC_DELTA_GET   MESHX_MODEL_OP_2(0x82, 0x3E)

MESHX_MODEL_OP_TAI_UTC_DELTA_SET

#define MESHX_MODEL_OP_TAI_UTC_DELTA_SET   MESHX_MODEL_OP_2(0x82, 0x3F)

MESHX_MODEL_OP_TAI_UTC_DELTA_STATUS

#define MESHX_MODEL_OP_TAI_UTC_DELTA_STATUS   MESHX_MODEL_OP_2(0x82, 0x40)

Scene Message Opcode

MESHX_MODEL_OP_TIME_GET

#define MESHX_MODEL_OP_TIME_GET   MESHX_MODEL_OP_2(0x82, 0x37)

MESHX_MODEL_OP_TIME_ROLE_GET

#define MESHX_MODEL_OP_TIME_ROLE_GET   MESHX_MODEL_OP_2(0x82, 0x38)

MESHX_MODEL_OP_TIME_ROLE_SET

#define MESHX_MODEL_OP_TIME_ROLE_SET   MESHX_MODEL_OP_2(0x82, 0x39)

MESHX_MODEL_OP_TIME_ROLE_STATUS

#define MESHX_MODEL_OP_TIME_ROLE_STATUS   MESHX_MODEL_OP_2(0x82, 0x3A)

MESHX_MODEL_OP_TIME_SET

#define MESHX_MODEL_OP_TIME_SET   MESHX_MODEL_OP_1(0x5C)

MESHX_MODEL_OP_TIME_STATUS

#define MESHX_MODEL_OP_TIME_STATUS   MESHX_MODEL_OP_1(0x5D)

MESHX_MODEL_OP_TIME_ZONE_GET

#define MESHX_MODEL_OP_TIME_ZONE_GET   MESHX_MODEL_OP_2(0x82, 0x3B)

MESHX_MODEL_OP_TIME_ZONE_SET

#define MESHX_MODEL_OP_TIME_ZONE_SET   MESHX_MODEL_OP_2(0x82, 0x3C)

MESHX_MODEL_OP_TIME_ZONE_STATUS

#define MESHX_MODEL_OP_TIME_ZONE_STATUS   MESHX_MODEL_OP_2(0x82, 0x3D)

MESHX_MODEL_OP_VENDOR_MODEL_APP_GET

#define MESHX_MODEL_OP_VENDOR_MODEL_APP_GET   MESHX_MODEL_OP_2(0x80, 0x4D)

Config Vendor Model App Get

MESHX_MODEL_OP_VENDOR_MODEL_APP_LIST

#define MESHX_MODEL_OP_VENDOR_MODEL_APP_LIST   MESHX_MODEL_OP_2(0x80, 0x4E)

MESHX_MODEL_OP_VENDOR_MODEL_SUB_GET

#define MESHX_MODEL_OP_VENDOR_MODEL_SUB_GET   MESHX_MODEL_OP_2(0x80, 0x2B)

Config Vendor Model Subscription Get

MESHX_MODEL_OP_VENDOR_MODEL_SUB_LIST

#define MESHX_MODEL_OP_VENDOR_MODEL_SUB_LIST   MESHX_MODEL_OP_2(0x80, 0x2C)

MESHX_SETTINGS_UID_SIZE

#define MESHX_SETTINGS_UID_SIZE   20

This enum value is the event of node/provisioner/fast provisioning

MESHX_UUID_ADDR_LEN

#define MESHX_UUID_ADDR_LEN   16

MESHX_UUID_EMPTY

#define MESHX_UUID_EMPTY   (meshx_uuid_addr_t){0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}

MESHX_VND_MODEL_CID_MESHX

#define MESHX_VND_MODEL_CID_MESHX   0x02E5

Foundation Models

Typedef Documentation

meshx_addr_type_t

typedef unsigned char meshx_addr_type_t

meshx_bd_addr_t

typedef uint8_t meshx_bd_addr_t[6]

meshx_cptr_t

typedef const void* meshx_cptr_t

meshx_ptr_t

typedef void* meshx_ptr_t

meshx_uuid_addr_t

typedef uint8_t meshx_uuid_addr_t[16]

Enumeration Type Documentation

meshx_cb_type_t

enum meshx_cb_type_t

Enumerator
MESHX_TYPE_PROV_CB
MESHX_TYPE_OUTPUT_NUM_CB
MESHX_TYPE_OUTPUT_STR_CB
MESHX_TYPE_INTPUT_CB
MESHX_TYPE_LINK_OPEN_CB
MESHX_TYPE_LINK_CLOSE_CB
MESHX_TYPE_COMPLETE_CB
MESHX_TYPE_RESET_CB

             {
    MESHX_TYPE_PROV_CB,
    MESHX_TYPE_OUTPUT_NUM_CB,
    MESHX_TYPE_OUTPUT_STR_CB,
    MESHX_TYPE_INTPUT_CB,
    MESHX_TYPE_LINK_OPEN_CB,
    MESHX_TYPE_LINK_CLOSE_CB,
    MESHX_TYPE_COMPLETE_CB,
    MESHX_TYPE_RESET_CB,
} meshx_cb_type_t;

meshx_input_action_t

enum meshx_input_action_t

Enumerator
MESHX_NO_INPUT	0
MESHX_PUSH	(1UL << (0))
MESHX_TWIST	(1UL << (1))
MESHX_ENTER_NUMBER	(1UL << (2))
MESHX_ENTER_STRING	(1UL << (3))

             {
    MESHX_NO_INPUT      = 0,
    MESHX_PUSH          = MESHX_BIT(0),
    MESHX_TWIST         = MESHX_BIT(1),
    MESHX_ENTER_NUMBER  = MESHX_BIT(2),
    MESHX_ENTER_STRING  = MESHX_BIT(3),
} meshx_input_action_t;

meshx_oob_method_t

enum meshx_oob_method_t

Enumerator
MESHX_NO_OOB
MESHX_STATIC_OOB
MESHX_OUTPUT_OOB
MESHX_INPUT_OOB

             {
    MESHX_NO_OOB,
    MESHX_STATIC_OOB,
    MESHX_OUTPUT_OOB,
    MESHX_INPUT_OOB,
} meshx_oob_method_t;

meshx_output_action_t

enum meshx_output_action_t

Enumerator
MESHX_NO_OUTPUT	0
MESHX_BLINK	(1UL << (0))
MESHX_BEEP	(1UL << (1))
MESHX_VIBRATE	(1UL << (2))
MESHX_DISPLAY_NUMBER	(1UL << (3))
MESHX_DISPLAY_STRING	(1UL << (4))

             {
    MESHX_NO_OUTPUT       = 0,
    MESHX_BLINK           = MESHX_BIT(0),
    MESHX_BEEP            = MESHX_BIT(1),
    MESHX_VIBRATE         = MESHX_BIT(2),
    MESHX_DISPLAY_NUMBER  = MESHX_BIT(3),
    MESHX_DISPLAY_STRING  = MESHX_BIT(4),
} meshx_output_action_t;

meshx_prov_cb_event_t

enum meshx_prov_cb_event_t

Enumerator
MESHX_PROV_REGISTER_COMP_EVT	Initialize BLE Mesh provisioning capabilities and internal data information completion event
MESHX_NODE_SET_UPROV_NAME_COMP_EVT	Set the unprovisioned device name completion event
MESHX_NODE_PROV_ENABLE_COMP_EVT	Enable node provisioning functionality completion event
MESHX_NODE_PROV_DISABLE_COMP_EVT	Disable node provisioning functionality completion event
MESHX_NODE_PROV_LINK_OPEN_EVT	Establish a BLE Mesh link event
MESHX_NODE_PROV_LINK_CLOSE_EVT	Close a BLE Mesh link event
MESHX_NODE_PROV_OOB_PUB_KEY_EVT	Generate Node input OOB public key event
MESHX_NODE_PROV_OUTPUT_NUMBER_EVT	Generate Node Output Number event
MESHX_NODE_PROV_OUTPUT_STRING_EVT	Generate Node Output String event
MESHX_NODE_PROV_INPUT_EVT	Event requiring the user to input a number or string
MESHX_NODE_PROV_COMPLETE_EVT	Provisioning done event
MESHX_NODE_PROV_RESET_EVT	Provisioning reset event
MESHX_NODE_PROV_SET_OOB_PUB_KEY_COMP_EVT	Node set oob public key completion event
MESHX_NODE_PROV_INPUT_NUMBER_COMP_EVT	Node input number completion event
MESHX_NODE_PROV_INPUT_STRING_COMP_EVT	Node input string completion event
MESHX_NODE_PROXY_IDENTITY_ENABLE_COMP_EVT	Enable BLE Mesh Proxy Identity advertising completion event
MESHX_NODE_PRIVATE_PROXY_IDENTITY_ENABLE_COMP_EVT	Enable BLE Mesh Private Proxy Identity advertising completion event
MESHX_NODE_PRIVATE_PROXY_IDENTITY_DISABLE_COMP_EVT	Disable BLE Mesh Private Proxy Identity advertising completion event
MESHX_NODE_PROXY_GATT_ENABLE_COMP_EVT	Enable BLE Mesh GATT Proxy Service completion event
MESHX_NODE_PROXY_GATT_DISABLE_COMP_EVT	Disable BLE Mesh GATT Proxy Service completion event
MESHX_NODE_ADD_LOCAL_NET_KEY_COMP_EVT	Node add NetKey locally completion event
MESHX_NODE_ADD_LOCAL_APP_KEY_COMP_EVT	Node add AppKey locally completion event
MESHX_NODE_BIND_APP_KEY_TO_MODEL_COMP_EVT	Node bind AppKey to model locally completion event
MESHX_PROVISIONER_PROV_ENABLE_COMP_EVT	Provisioner enable provisioning functionality completion event
MESHX_PROVISIONER_PROV_DISABLE_COMP_EVT	Provisioner disable provisioning functionality completion event
MESHX_PROVISIONER_RECV_UNPROV_ADV_PKT_EVT	Provisioner receives unprovisioned device beacon event
MESHX_PROVISIONER_PROV_READ_OOB_PUB_KEY_EVT	Provisioner read unprovisioned device OOB public key event
MESHX_PROVISIONER_PROV_INPUT_EVT	Provisioner input value for provisioning procedure event
MESHX_PROVISIONER_PROV_OUTPUT_EVT	Provisioner output value for provisioning procedure event
MESHX_PROVISIONER_PROV_LINK_OPEN_EVT	Provisioner establish a BLE Mesh link event
MESHX_PROVISIONER_PROV_LINK_CLOSE_EVT	Provisioner close a BLE Mesh link event
MESHX_PROVISIONER_PROV_COMPLETE_EVT	Provisioner provisioning done event
MESHX_PROVISIONER_CERT_BASED_PROV_START_EVT	Provisioner initiate a certificate based provisioning
MESHX_PROVISIONER_RECV_PROV_RECORDS_LIST_EVT	Provisioner receive provisioning records list event
MESHX_PROVISIONER_PROV_RECORD_RECV_COMP_EVT	Provisioner receive provisioning record complete event
MESHX_PROVISIONER_SEND_PROV_RECORDS_GET_EVT	Provisioner send provisioning records get to device event
MESHX_PROVISIONER_SEND_PROV_RECORD_REQUEST_EVT	Provisioner send provisioning record request to device event
MESHX_PROVISIONER_SEND_PROV_INVITE_EVT	Provisioner send provisioning invite to device event
MESHX_PROVISIONER_SEND_LINK_CLOSE_EVT	Provisioner send link close to device event
MESHX_PROVISIONER_ADD_UNPROV_DEV_COMP_EVT	Provisioner add a device to the list which contains devices that are waiting/going to be provisioned completion event
MESHX_PROVISIONER_PROV_DEV_WITH_ADDR_COMP_EVT	Provisioner start to provision an unprovisioned device completion event
MESHX_PROVISIONER_DELETE_DEV_COMP_EVT	Provisioner delete a device from the list, close provisioning link with the device completion event
MESHX_PROVISIONER_SET_DEV_UUID_MATCH_COMP_EVT	Provisioner set the value to be compared with part of the unprovisioned device UUID completion event
MESHX_PROVISIONER_SET_PROV_DATA_INFO_COMP_EVT	Provisioner set net_idx/flags/iv_index used for provisioning completion event
MESHX_PROVISIONER_SET_STATIC_OOB_VALUE_COMP_EVT	Provisioner set static oob value used for provisioning completion event
MESHX_PROVISIONER_SET_PRIMARY_ELEM_ADDR_COMP_EVT	Provisioner set unicast address of primary element completion event
MESHX_PROVISIONER_PROV_READ_OOB_PUB_KEY_COMP_EVT	Provisioner read unprovisioned device OOB public key completion event
MESHX_PROVISIONER_PROV_INPUT_NUMBER_COMP_EVT	Provisioner input number completion event
MESHX_PROVISIONER_PROV_INPUT_STRING_COMP_EVT	Provisioner input string completion event
MESHX_PROVISIONER_SET_NODE_NAME_COMP_EVT	Provisioner set node name completion event
MESHX_PROVISIONER_ADD_LOCAL_APP_KEY_COMP_EVT	Provisioner add local app key completion event
MESHX_PROVISIONER_UPDATE_LOCAL_APP_KEY_COMP_EVT	Provisioner update local app key completion event
MESHX_PROVISIONER_BIND_APP_KEY_TO_MODEL_COMP_EVT	Provisioner bind local model with local app key completion event
MESHX_PROVISIONER_ADD_LOCAL_NET_KEY_COMP_EVT	Provisioner add local network key completion event
MESHX_PROVISIONER_UPDATE_LOCAL_NET_KEY_COMP_EVT	Provisioner update local network key completion event
MESHX_PROVISIONER_STORE_NODE_COMP_DATA_COMP_EVT	Provisioner store node composition data completion event
MESHX_PROVISIONER_DELETE_NODE_WITH_UUID_COMP_EVT	Provisioner delete node with uuid completion event
MESHX_PROVISIONER_DELETE_NODE_WITH_ADDR_COMP_EVT	Provisioner delete node with unicast address completion event
MESHX_PROVISIONER_ENABLE_HEARTBEAT_RECV_COMP_EVT	Provisioner start to receive heartbeat message completion event
MESHX_PROVISIONER_SET_HEARTBEAT_FILTER_TYPE_COMP_EVT	Provisioner set the heartbeat filter type completion event
MESHX_PROVISIONER_SET_HEARTBEAT_FILTER_INFO_COMP_EVT	Provisioner set the heartbeat filter information completion event
MESHX_PROVISIONER_RECV_HEARTBEAT_MESSAGE_EVT	Provisioner receive heartbeat message event
MESHX_PROVISIONER_DIRECT_ERASE_SETTINGS_COMP_EVT	Provisioner directly erase settings completion event
MESHX_PROVISIONER_OPEN_SETTINGS_WITH_INDEX_COMP_EVT	Provisioner open settings with index completion event
MESHX_PROVISIONER_OPEN_SETTINGS_WITH_UID_COMP_EVT	Provisioner open settings with user id completion event
MESHX_PROVISIONER_CLOSE_SETTINGS_WITH_INDEX_COMP_EVT	Provisioner close settings with index completion event
MESHX_PROVISIONER_CLOSE_SETTINGS_WITH_UID_COMP_EVT	Provisioner close settings with user id completion event
MESHX_PROVISIONER_DELETE_SETTINGS_WITH_INDEX_COMP_EVT	Provisioner delete settings with index completion event
MESHX_PROVISIONER_DELETE_SETTINGS_WITH_UID_COMP_EVT	Provisioner delete settings with user id completion event
MESHX_SET_FAST_PROV_INFO_COMP_EVT	Set fast provisioning information (e.g. unicast address range, net_idx, etc.) completion event
MESHX_SET_FAST_PROV_ACTION_COMP_EVT	Set fast provisioning action completion event
MESHX_HEARTBEAT_MESSAGE_RECV_EVT	Receive Heartbeat message event
MESHX_LPN_ENABLE_COMP_EVT	Enable Low Power Node completion event
MESHX_LPN_DISABLE_COMP_EVT	Disable Low Power Node completion event
MESHX_LPN_POLL_COMP_EVT	Low Power Node send Friend Poll completion event
MESHX_LPN_FRIENDSHIP_ESTABLISH_EVT	Low Power Node establishes friendship event
MESHX_LPN_FRIENDSHIP_TERMINATE_EVT	Low Power Node terminates friendship event
MESHX_FRIEND_FRIENDSHIP_ESTABLISH_EVT	Friend Node establishes friendship event
MESHX_FRIEND_FRIENDSHIP_TERMINATE_EVT	Friend Node terminates friendship event
MESHX_PROXY_CLIENT_RECV_ADV_PKT_EVT	Proxy Client receives Network ID advertising packet event
MESHX_PROXY_CLIENT_CONNECTED_EVT	Proxy Client establishes connection successfully event
MESHX_PROXY_CLIENT_DISCONNECTED_EVT	Proxy Client terminates connection successfully event
MESHX_PROXY_CLIENT_RECV_FILTER_STATUS_EVT	Proxy Client receives Proxy Filter Status event
MESHX_PROXY_CLIENT_CONNECT_COMP_EVT	Proxy Client connect completion event
MESHX_PROXY_CLIENT_DISCONNECT_COMP_EVT	Proxy Client disconnect completion event
MESHX_PROXY_CLIENT_SET_FILTER_TYPE_COMP_EVT	Proxy Client set filter type completion event
MESHX_PROXY_CLIENT_ADD_FILTER_ADDR_COMP_EVT	Proxy Client add filter address completion event
MESHX_PROXY_CLIENT_REMOVE_FILTER_ADDR_COMP_EVT	Proxy Client remove filter address completion event
MESHX_PROXY_CLIENT_DIRECTED_PROXY_SET_COMP_EVT	Proxy Client directed proxy set completion event
MESHX_PROXY_SERVER_CONNECTED_EVT	Proxy Server establishes connection successfully event
MESHX_PROXY_SERVER_DISCONNECTED_EVT	Proxy Server terminates connection successfully event
MESHX_PROXY_CLIENT_SEND_SOLIC_PDU_COMP_EVT	Proxy Client send Solicitation PDU completion event
MESHX_MODEL_SUBSCRIBE_GROUP_ADDR_COMP_EVT	Local model subscribes group address completion event
MESHX_MODEL_UNSUBSCRIBE_GROUP_ADDR_COMP_EVT	Local model unsubscribes group address completion event
MESHX_DEINIT_MESH_COMP_EVT	De-initialize BLE Mesh stack completion event
MESHX_PROV_EVT_MAX

             {
    MESHX_PROV_REGISTER_COMP_EVT,                        /*!< Initialize BLE Mesh provisioning capabilities and internal data information completion event */
    MESHX_NODE_SET_UPROV_NAME_COMP_EVT,                  /*!< Set the unprovisioned device name completion event */
    MESHX_NODE_PROV_ENABLE_COMP_EVT,                     /*!< Enable node provisioning functionality completion event */
    MESHX_NODE_PROV_DISABLE_COMP_EVT,                    /*!< Disable node provisioning functionality completion event */
    MESHX_NODE_PROV_LINK_OPEN_EVT,                       /*!< Establish a BLE Mesh link event */
    MESHX_NODE_PROV_LINK_CLOSE_EVT,                      /*!< Close a BLE Mesh link event */
    MESHX_NODE_PROV_OOB_PUB_KEY_EVT,                     /*!< Generate Node input OOB public key event */
    MESHX_NODE_PROV_OUTPUT_NUMBER_EVT,                   /*!< Generate Node Output Number event */
    MESHX_NODE_PROV_OUTPUT_STRING_EVT,                   /*!< Generate Node Output String event */
    MESHX_NODE_PROV_INPUT_EVT,                           /*!< Event requiring the user to input a number or string */
    MESHX_NODE_PROV_COMPLETE_EVT,                        /*!< Provisioning done event */
    MESHX_NODE_PROV_RESET_EVT,                           /*!< Provisioning reset event */
    MESHX_NODE_PROV_SET_OOB_PUB_KEY_COMP_EVT,            /*!< Node set oob public key completion event */
    MESHX_NODE_PROV_INPUT_NUMBER_COMP_EVT,               /*!< Node input number completion event */
    MESHX_NODE_PROV_INPUT_STRING_COMP_EVT,               /*!< Node input string completion event */
    MESHX_NODE_PROXY_IDENTITY_ENABLE_COMP_EVT,           /*!< Enable BLE Mesh Proxy Identity advertising completion event */
    MESHX_NODE_PRIVATE_PROXY_IDENTITY_ENABLE_COMP_EVT,   /*!< Enable BLE Mesh Private Proxy Identity advertising completion event */
    MESHX_NODE_PRIVATE_PROXY_IDENTITY_DISABLE_COMP_EVT,  /*!< Disable BLE Mesh Private Proxy Identity advertising completion event */
    MESHX_NODE_PROXY_GATT_ENABLE_COMP_EVT,               /*!< Enable BLE Mesh GATT Proxy Service completion event */
    MESHX_NODE_PROXY_GATT_DISABLE_COMP_EVT,              /*!< Disable BLE Mesh GATT Proxy Service completion event */
    MESHX_NODE_ADD_LOCAL_NET_KEY_COMP_EVT,               /*!< Node add NetKey locally completion event */
    MESHX_NODE_ADD_LOCAL_APP_KEY_COMP_EVT,               /*!< Node add AppKey locally completion event */
    MESHX_NODE_BIND_APP_KEY_TO_MODEL_COMP_EVT,           /*!< Node bind AppKey to model locally completion event */
    MESHX_PROVISIONER_PROV_ENABLE_COMP_EVT,              /*!< Provisioner enable provisioning functionality completion event */
    MESHX_PROVISIONER_PROV_DISABLE_COMP_EVT,             /*!< Provisioner disable provisioning functionality completion event */
    MESHX_PROVISIONER_RECV_UNPROV_ADV_PKT_EVT,           /*!< Provisioner receives unprovisioned device beacon event */
    MESHX_PROVISIONER_PROV_READ_OOB_PUB_KEY_EVT,         /*!< Provisioner read unprovisioned device OOB public key event */
    MESHX_PROVISIONER_PROV_INPUT_EVT,                    /*!< Provisioner input value for provisioning procedure event */
    MESHX_PROVISIONER_PROV_OUTPUT_EVT,                   /*!< Provisioner output value for provisioning procedure event */
    MESHX_PROVISIONER_PROV_LINK_OPEN_EVT,                /*!< Provisioner establish a BLE Mesh link event */
    MESHX_PROVISIONER_PROV_LINK_CLOSE_EVT,               /*!< Provisioner close a BLE Mesh link event */
    MESHX_PROVISIONER_PROV_COMPLETE_EVT,                 /*!< Provisioner provisioning done event */
    MESHX_PROVISIONER_CERT_BASED_PROV_START_EVT,         /*!< Provisioner initiate a certificate based provisioning */
    MESHX_PROVISIONER_RECV_PROV_RECORDS_LIST_EVT,        /*!< Provisioner receive provisioning records list event */
    MESHX_PROVISIONER_PROV_RECORD_RECV_COMP_EVT,         /*!< Provisioner receive provisioning record complete event */
    MESHX_PROVISIONER_SEND_PROV_RECORDS_GET_EVT,         /*!< Provisioner send provisioning records get to device event */
    MESHX_PROVISIONER_SEND_PROV_RECORD_REQUEST_EVT,      /*!< Provisioner send provisioning record request to device event */
    MESHX_PROVISIONER_SEND_PROV_INVITE_EVT,              /*!< Provisioner send provisioning invite to device event */
    MESHX_PROVISIONER_SEND_LINK_CLOSE_EVT,               /*!< Provisioner send link close to device event */
    MESHX_PROVISIONER_ADD_UNPROV_DEV_COMP_EVT,           /*!< Provisioner add a device to the list which contains devices that are waiting/going to be provisioned completion event */
    MESHX_PROVISIONER_PROV_DEV_WITH_ADDR_COMP_EVT,       /*!< Provisioner start to provision an unprovisioned device completion event */
    MESHX_PROVISIONER_DELETE_DEV_COMP_EVT,               /*!< Provisioner delete a device from the list, close provisioning link with the device completion event */
    MESHX_PROVISIONER_SET_DEV_UUID_MATCH_COMP_EVT,       /*!< Provisioner set the value to be compared with part of the unprovisioned device UUID completion event */
    MESHX_PROVISIONER_SET_PROV_DATA_INFO_COMP_EVT,       /*!< Provisioner set net_idx/flags/iv_index used for provisioning completion event */
    MESHX_PROVISIONER_SET_STATIC_OOB_VALUE_COMP_EVT,     /*!< Provisioner set static oob value used for provisioning completion event */
    MESHX_PROVISIONER_SET_PRIMARY_ELEM_ADDR_COMP_EVT,    /*!< Provisioner set unicast address of primary element completion event */
    MESHX_PROVISIONER_PROV_READ_OOB_PUB_KEY_COMP_EVT,    /*!< Provisioner read unprovisioned device OOB public key completion event */
    MESHX_PROVISIONER_PROV_INPUT_NUMBER_COMP_EVT,        /*!< Provisioner input number completion event */
    MESHX_PROVISIONER_PROV_INPUT_STRING_COMP_EVT,        /*!< Provisioner input string completion event */
    MESHX_PROVISIONER_SET_NODE_NAME_COMP_EVT,            /*!< Provisioner set node name completion event */
    MESHX_PROVISIONER_ADD_LOCAL_APP_KEY_COMP_EVT,        /*!< Provisioner add local app key completion event */
    MESHX_PROVISIONER_UPDATE_LOCAL_APP_KEY_COMP_EVT,     /*!< Provisioner update local app key completion event */
    MESHX_PROVISIONER_BIND_APP_KEY_TO_MODEL_COMP_EVT,    /*!< Provisioner bind local model with local app key completion event */
    MESHX_PROVISIONER_ADD_LOCAL_NET_KEY_COMP_EVT,        /*!< Provisioner add local network key completion event */
    MESHX_PROVISIONER_UPDATE_LOCAL_NET_KEY_COMP_EVT,     /*!< Provisioner update local network key completion event */
    MESHX_PROVISIONER_STORE_NODE_COMP_DATA_COMP_EVT,     /*!< Provisioner store node composition data completion event */
    MESHX_PROVISIONER_DELETE_NODE_WITH_UUID_COMP_EVT,    /*!< Provisioner delete node with uuid completion event */
    MESHX_PROVISIONER_DELETE_NODE_WITH_ADDR_COMP_EVT,    /*!< Provisioner delete node with unicast address completion event */
    MESHX_PROVISIONER_ENABLE_HEARTBEAT_RECV_COMP_EVT,     /*!< Provisioner start to receive heartbeat message completion event */
    MESHX_PROVISIONER_SET_HEARTBEAT_FILTER_TYPE_COMP_EVT, /*!< Provisioner set the heartbeat filter type completion event */
    MESHX_PROVISIONER_SET_HEARTBEAT_FILTER_INFO_COMP_EVT, /*!< Provisioner set the heartbeat filter information completion event */
    MESHX_PROVISIONER_RECV_HEARTBEAT_MESSAGE_EVT,         /*!< Provisioner receive heartbeat message event */
    MESHX_PROVISIONER_DIRECT_ERASE_SETTINGS_COMP_EVT,        /*!< Provisioner directly erase settings completion event */
    MESHX_PROVISIONER_OPEN_SETTINGS_WITH_INDEX_COMP_EVT,     /*!< Provisioner open settings with index completion event */
    MESHX_PROVISIONER_OPEN_SETTINGS_WITH_UID_COMP_EVT,       /*!< Provisioner open settings with user id completion event */
    MESHX_PROVISIONER_CLOSE_SETTINGS_WITH_INDEX_COMP_EVT,    /*!< Provisioner close settings with index completion event */
    MESHX_PROVISIONER_CLOSE_SETTINGS_WITH_UID_COMP_EVT,      /*!< Provisioner close settings with user id completion event */
    MESHX_PROVISIONER_DELETE_SETTINGS_WITH_INDEX_COMP_EVT,   /*!< Provisioner delete settings with index completion event */
    MESHX_PROVISIONER_DELETE_SETTINGS_WITH_UID_COMP_EVT,     /*!< Provisioner delete settings with user id completion event */
    MESHX_SET_FAST_PROV_INFO_COMP_EVT,                   /*!< Set fast provisioning information (e.g. unicast address range, net_idx, etc.) completion event */
    MESHX_SET_FAST_PROV_ACTION_COMP_EVT,                 /*!< Set fast provisioning action completion event */
    MESHX_HEARTBEAT_MESSAGE_RECV_EVT,                    /*!< Receive Heartbeat message event */
    MESHX_LPN_ENABLE_COMP_EVT,                           /*!< Enable Low Power Node completion event */
    MESHX_LPN_DISABLE_COMP_EVT,                          /*!< Disable Low Power Node completion event */
    MESHX_LPN_POLL_COMP_EVT,                             /*!< Low Power Node send Friend Poll completion event */
    MESHX_LPN_FRIENDSHIP_ESTABLISH_EVT,                  /*!< Low Power Node establishes friendship event */
    MESHX_LPN_FRIENDSHIP_TERMINATE_EVT,                  /*!< Low Power Node terminates friendship event */
    MESHX_FRIEND_FRIENDSHIP_ESTABLISH_EVT,               /*!< Friend Node establishes friendship event */
    MESHX_FRIEND_FRIENDSHIP_TERMINATE_EVT,               /*!< Friend Node terminates friendship event */
    MESHX_PROXY_CLIENT_RECV_ADV_PKT_EVT,                 /*!< Proxy Client receives Network ID advertising packet event */
    MESHX_PROXY_CLIENT_CONNECTED_EVT,                    /*!< Proxy Client establishes connection successfully event */
    MESHX_PROXY_CLIENT_DISCONNECTED_EVT,                 /*!< Proxy Client terminates connection successfully event */
    MESHX_PROXY_CLIENT_RECV_FILTER_STATUS_EVT,           /*!< Proxy Client receives Proxy Filter Status event */
    MESHX_PROXY_CLIENT_CONNECT_COMP_EVT,                 /*!< Proxy Client connect completion event */
    MESHX_PROXY_CLIENT_DISCONNECT_COMP_EVT,              /*!< Proxy Client disconnect completion event */
    MESHX_PROXY_CLIENT_SET_FILTER_TYPE_COMP_EVT,         /*!< Proxy Client set filter type completion event */
    MESHX_PROXY_CLIENT_ADD_FILTER_ADDR_COMP_EVT,         /*!< Proxy Client add filter address completion event */
    MESHX_PROXY_CLIENT_REMOVE_FILTER_ADDR_COMP_EVT,      /*!< Proxy Client remove filter address completion event */
    MESHX_PROXY_CLIENT_DIRECTED_PROXY_SET_COMP_EVT,      /*!< Proxy Client directed proxy set completion event */
    MESHX_PROXY_SERVER_CONNECTED_EVT,                    /*!< Proxy Server establishes connection successfully event */
    MESHX_PROXY_SERVER_DISCONNECTED_EVT,                 /*!< Proxy Server terminates connection successfully event */
    MESHX_PROXY_CLIENT_SEND_SOLIC_PDU_COMP_EVT,          /*!< Proxy Client send Solicitation PDU completion event */
    MESHX_MODEL_SUBSCRIBE_GROUP_ADDR_COMP_EVT,           /*!< Local model subscribes group address completion event */
    MESHX_MODEL_UNSUBSCRIBE_GROUP_ADDR_COMP_EVT,         /*!< Local model unsubscribes group address completion event */
    MESHX_DEINIT_MESH_COMP_EVT,                          /*!< De-initialize BLE Mesh stack completion event */
    MESHX_PROV_EVT_MAX,
} meshx_prov_cb_event_t;
