Structure to hold the parameters for sending a Generic Ctl message. More...
#include <meshx_light_ctl_client.h>
Data Fields | |
| meshx_light_ctl_client_model_t * | model |
| uint8_t | tid |
| uint16_t | element_id |
| uint16_t | opcode |
| uint16_t | addr |
| uint16_t | net_idx |
| uint16_t | app_idx |
| uint16_t | lightness |
| uint16_t | temperature |
| uint16_t | delta_uv |
| uint16_t | temp_range_max |
| uint16_t | temp_range_min |
Detailed Description
Structure to hold the parameters for sending a Generic Ctl message.
Definition at line 68 of file meshx_light_ctl_client.h.
Field Documentation
◆ addr
| uint16_t meshx_gen_ctl_send_params::addr |
The destination address of the message.
Definition at line 74 of file meshx_light_ctl_client.h.
◆ app_idx
| uint16_t meshx_gen_ctl_send_params::app_idx |
The application index of the message.
Definition at line 76 of file meshx_light_ctl_client.h.
◆ delta_uv
| uint16_t meshx_gen_ctl_send_params::delta_uv |
The desired delta UV value.
Definition at line 79 of file meshx_light_ctl_client.h.
◆ element_id
| uint16_t meshx_gen_ctl_send_params::element_id |
The ID of the element to which the message is sent.
Definition at line 72 of file meshx_light_ctl_client.h.
◆ lightness
| uint16_t meshx_gen_ctl_send_params::lightness |
The desired lightness value.
Definition at line 77 of file meshx_light_ctl_client.h.
◆ model
| meshx_light_ctl_client_model_t* meshx_gen_ctl_send_params::model |
Pointer to the CTL client model.
Definition at line 70 of file meshx_light_ctl_client.h.
◆ net_idx
| uint16_t meshx_gen_ctl_send_params::net_idx |
The network index of the message.
Definition at line 75 of file meshx_light_ctl_client.h.
◆ opcode
| uint16_t meshx_gen_ctl_send_params::opcode |
The opcode of the message.
Definition at line 73 of file meshx_light_ctl_client.h.
◆ temp_range_max
| uint16_t meshx_gen_ctl_send_params::temp_range_max |
The maximum temperature range.
Definition at line 80 of file meshx_light_ctl_client.h.
◆ temp_range_min
| uint16_t meshx_gen_ctl_send_params::temp_range_min |
The minimum temperature range.
Definition at line 81 of file meshx_light_ctl_client.h.
◆ temperature
| uint16_t meshx_gen_ctl_send_params::temperature |
The desired temperature value.
Definition at line 78 of file meshx_light_ctl_client.h.
◆ tid
| uint8_t meshx_gen_ctl_send_params::tid |
The transaction identifier for the message.
Definition at line 71 of file meshx_light_ctl_client.h.
The documentation for this struct was generated from the following file:
